Fully Automatic Ceiling Fan Motor Coil Winding Machine Fan Inner Outer Slot Stator Winder Machine
Tianjin Grewin Technology Co., Ltd.- Voltage：220V
- Wire Diameter：0.08-1.00mm
- Winding Width：200mm
- Spread Width：200mm
- Winding Motor：1,8HP DC Motor
- Spread Motor：Stepping Motor
Base Info
- Model NO.：ADSGW22-2
- Memory Number：999
- Max.Winding Speed：3000rpm
- Supply Voltage：AC 220V(50Hz)
- Mechanical Dimensions：760*680*720
- Weight：37kgs
- Name 1：Coil Winder Machine
- Name 2：Transformer Winding Machine
- Automatic：Automatic
- Certification：RoHS, CE, ISO
- Transport Package：Export Standard Carton or Customize Strong Pallet
- Specification：CE
- Trademark：Grewin
- Origin：China
- HS Code：84798110
- Production Capacity：100PCS
Description
Specifications
| Wire size range | 0.03-0.8mm |
| Winder width | 0-110mm |
| No. Of spindle | 1spindle |
| Main motor | DC Brushless 400W |
| Winding Motor | Stepping motor |
| Machine Max speed | 6000RPM |
| Memory groups | 999 |
| Power | AC220V/50HZ |
| Machine weight | 30kg |
| Machine size | 420mm*320mm*420mm |
ACGW22-60 Transformer Coil winding Machine
Specifications:
| Spindle number | 6 |
| Wire size range | 0.05-0.35mm |
| Loop diameter | 70mm |
| The max wire spacing | 9.99mm |
| Winder width | 60mm |
| Spindle pitch | 85mm |
| Max speed | 0-7000 RPM |
| Spindle motor | Three Phase motor+AC Drives |
| Winder motor | Stepping motor |
| Input power | 220V 50HZ/60HZ |
| Machine size | 920×780×950mm |
| Package size | 1000×830×1130mm |
| Net weight | 120kg |
| Gross weight | 150kg |
GW-9740 Manual Winding Machine
SPECIFICATION:
| Spindles | 1 | Max Speed | 3000rpm |
| Wire diameter | 0.03-0.5mm | Memory | 99 Sequences |
| Main Motor | Swing Motor | Power Source | AC 220V/110V±10%,50/60MHZ |
FEATURES:
Manual Winding Machine has microprocessor design ,easy for program-setting handing.
Manual Winding Machine sets winding direction ,brake time for each step independently
More convenience by using foot-switch.
Manual Winding Machine is easy to use VR-switch to adjust the speed of winding.
Wire tensioner with magnetic braking provides constant wire tension.
ADVANTAGES:
CE certification.
A short period of delivery:10 days after receipt of payment.
Free replacement of mainframe accessories.
The technicians are experienced for up 5 years.
How to select the best suited automatic toroid taping machine for your toroid coil?
Tell us your toroidal coil of data as below please:
1.toroid core outside diameter before winding?
2.toroid core inside diameter before winding?
3.toroid core height before winding?
4.how many windings on this core?
5.how many tape windings total on this toroidal coil?
6.how about the tape width of each tape winding?
7.how many turns of each tape winding?
8.provide pictures of product which is better.
Packaging Information:
Wooden case package: For larger scale goods as machine equipment etc, we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock. We will inform you the delivery note. You just need to wait for phone call, then pick up the goods at the nearest logistic station .(Please let me know in advance if you want get the goods at home.) Packaging: Packaging material: Carton/Wooden case with foam inside.
Why Choose Us1.Environmental protection, low noise and high efficiency;
2.The storage capacity can be super large.
3.You can choose different row direction, winding angle and sectional angle.
4.Photoelectric induction switch technology has high accuracy and accurate number of rings.
5.Stepper motor wiring, spacing can be accurately controlled;
6.Products that can be tetragonal.
Packaging & Shipping
General package(Paper carton or plastic bag): For small goods, Package it with form and pack paper to guarantee unbroken during
the transport.
Wooden case package: For larger scale goods as machine equipment etc, we have special skilled carpenter, who would make the proper
wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in
the wooden case to prevent crack and shock. We will inform you the delivery note. You just need to wait for phone call, then pick
up the goods at the nearest logistic station .(Please let me know in advance if you want get the goods at home.)
Packaging:
Packaging material: Carton/Wooden case with foam inside.
Shipping:
A. 3-5 workdays shipping from China by Air/Express(DHL,FedEx,UPS,EMS etc.)
B. 3-5 workdays shipping from UK Warehouse to European union countries.No need to pay for customs duties and VAT.
C. 25-30 workdays shipping from China to Russian customers. No need to pay for customs duties and VAT.
D. We can arrange shipment by sea. Minium CBM requirement : 1 CBM
1.We provide you the friendly English User manual or operating videos for free.
2.24 hours technical support by email or calling.
3.Warranty: 1 year free, 2-3 years cost price and free technical support always.
4.Free training to make sure you master the operating of our products.
5. OEM/ODM accept . But the MOQ of OEM/ODM is 100 sets.
Service tenet
Provide you the best service with "fast + satisfactory + safe".
Warranty period:
12 months long after the user received the product.
Warranty items:
Only for abnormal breakdown caused by the machine design or manufacture defect,free repair and accessory will be provided.
Technology service ability:
All service engineers with many years experience are gotten special technology training, who can deal with various breakdown
problem.
Guide the user to use accurately and how to maintain the product.
Provide free consultation about production process technology of electronic products.
Service after sell:
In order to guarantee the machine used normally, we'd have training on how to operate, use and maintain our product by English
manual, video, guiding on line.
Use instruction:
Apply for the right complete size of product, otherwise, the wrong dimensions will affect the use effect.
Do ensure using the product accord to the use instruction completely.Do not exceed the scope of application of the products.
Maintain the product after use,Damp proof, rust proof, leak proof, explosion-proof, regular maintenance and inspection should be
taken care. All done help to extend the use period.
