• Model NO.：HC-8022,8030
• Power Supply：220V
• Maximum Stripping Levels：9
• Incise Depth：0.01mm
• Max Stripping Length：80mm 200mm
• Productivity：Approx 300-500PCS,H
• Working Environment：0-50ºC Moderate Dry,Non-Shake
• Transport Package：Wooden Box
• Specification：620*230*360; 830*230*360mm
• Trademark：Hechang
• Origin：China
• HS Code：8479899990

Basic Info.

Model NO. HC-8022/8030 Power Supply 220V Maximum Stripping Levels 9 Incise Depth 0.01mm Max Stripping Length 80mm 200mm Productivity Approx 300-500PCS/H Working Environment 0-50ºC Moderate Dry,Non-Shake Transport Package Wooden Box Specification 620*230*360; 830*230*360mm Trademark Hechang Origin China HS Code 8479899990

Product Description

The HC-8022/8030 is used for big coaxial cables and special round wires . The strengthening of HC - 8015 edition
he rotating blade head of HC-8022/8030 is fitted with four  blades and four  centring units they improves the processing ability.
The HC-8022/8030 insulates multi-layered conductors in up to 9 steps. The processing steps can be programmed in any desired order. The cut parameters can be independently set and optimised for every level and do not need to change blades .
All mechanical parts adopt  Japan, Germany original pure import combining domestic accessories, the screw wear-resisting ability increase by more than 500%, more durable . it ensure product quality is stable, blade using the world's top heat treatment technology, make the blade more wear-resisting, more stable, calibration of imported equipment for blade straightness and flatness control, strict precision degree is high, can achieve 0.03 mm thickness tolerance of less than, blade the mirror surface processing, to ensure that the cutting resistance, wire cut is more beautiful.Has the characteristics of energy saving, low noise at the same time, the unique blade on three sides by grinding technology, increase the wear resistance than other ordinary blade by more than 30%, each machine processing after tens of thousands of times of simulation rear can put in storage
Feature:

High precise processing of micro conductors
Stripping in up to 9 steps
User-friendly display, Touch screen Ease of operation
Extremely low maintenance
Light and portable
Rotating stripping head with centring
Multi-step stripping


Specification:



Mode	HC-8022	HC-8030
Max outer diameter	22 mm	30mm
Incise depth	0.01 mm	0.01mm
Max stripping length	80mm	200mm
Maximum stripping levels	9 layers	9 layers
Min stripping length	0.1mm	0.1mm
Drive supply	Dynamo/roll shot silk stem drive	Dynamo/roll shot silk stem drive
Display	The touch holds	The touch holds
Blades	4 pieces  material: imported switzerland tungsten steel	4 pieces  material: imported switzerland tungsten steel
Centering slab	4peices  material: imported High speed steel	4peices  material: imported High speed steel
Trapper	,, Automatic self aligning ,motor drive ,the clamping process control	,, Automatic self aligning ,motor drive ,the clamping process control
Production rate	Approx 300- 500pcs/h (depending on conductor and programming)	Approx 300- 500pcs/h (depending on conductor and programming)
Database capacity	100 different conductors along with all processing parameters.	100 different conductors along with all processing parameters.
voltage	Voltage: 220V/50HZ    Power:380W	Voltage: 220V/50HZ    Power:380W
Weight	30KG	50KG
Outer dimensions	620×230×360(MM)	830×230×360(MM)
Working environment	0-50ºC moderate dry,non-shake	,,, 0-50ºC moderate dry,non-shake



Changzhou Hechang Machinery Co;Ltd is a Hi-tech professional manufacturer, Providing all-rounded solutions to wiring harness processing area for the customers from Electrical Appliances, Automotive,New Energy, Industrial Control Automation, instrument and apparatus,Medical ,Electric control cabinet , lighting and so on .

Our main products included Fully-automatic wire cut strip crimp machine, wire cut strip machine, Terminal crimping machine, wire cut strip and inkject marking ,wire tinning machine , Seal insertion, Applicators for terminal crimping, quality assurance , peripherals and other special wiring harness processing electronic equipments.
