Automatic Transformer Radiator Coil Foil Winding Machine

HANGZHOU LINAN XINRAN SOLAR EQUIPMENT CO., LTD.
  • Voltage：380V
  • Model：Prj-600
  • Winding Coil Outer Diameter：200-600mm
  • Coil Band Width：250-600mm
  • Coil Outer Diameter ( Max )：Less Than1000mm
  • Coil Winding Machine Speed：0-30 M,Min

Base Info

  • Compression Gas：Less Than 0.5MPa, 0.1m3,Min
  • Copper Foil Thickness：0.5-2 mm
  • Aluminum Foil Thickness：0.5-3mm
  • Welding Method：TIG Direct Current W Welder
  • Welding Speed：0-0.7m,Min
  • Floor Space Single：5040X3920mm
  • Floor Space Double：6260X3870mm
  • Automatic：Automatic
  • Transport Package：Steel Wire.
  • Specification：300-1300mm
  • Trademark：EN-SOURCE
  • Origin：China, Zhejiang
  • HS Code：84552210
  • Production Capacity：500

Description

Total weight Single5000Kg5500Kg6000Kg6500Kg7000Kg8000Kgdouble8000Kg8500Kg9000Kg9500Kg10000Kg11000Kg
II.The other photo of transformer radiator coil foil winding machine:
Automatic Transformer Radiator Coil Foil Winding Machine
Automatic Transformer Radiator Coil Foil Winding Machine

III. Contact Information:
Automatic Transformer Radiator Coil Foil Winding Machine
