• Model NO.：WIND-TW-7000
• Trademark：Wind Automation
• Origin：China
• HS Code：8479811000
• Production Capacity：100 Sets,Year

Basic Info.

Model NO. WIND-TW-7000 Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/Year

Product Description

Turbo-generator Coil Linear Tape Winding MachineSpecification1,Copper rods to be held by mechanical hands, holding force of the hands: 150kg;
2,Max. taping section: 145×45mm2;
3,Tape width 25mm, half overlapping 12.5mm, double taping 6.25mm (pitch is adjustable for CNC frequency conversion half-overlapping);

4,Max. straight part: 7m, min. 2.2m, 7 mechanical hands;
5,A pair of simulation constant tension tape disc (for mica tape, few adhesive tape); a pair of general adjustable tension tape disc (for medium adhesive tape, much adhesive tape);
6,Speed: 60~200r/min, frequency variable speed control;
7,Taping speed 8 times faster than manual operation, good quality.
