• Model NO.：PGB-700
• Driven Type：Electric
• Transport Package：Poly Wood Case
• Specification：700x700x80
• Trademark：Daheng
• Origin：China
• HS Code：8424899990
• Production Capacity：600

Basic Info.

Model NO. PGB-700 Driven Type Electric Transport Package Poly Wood Case Specification 700x700x80 Trademark Daheng Origin China HS Code 8424899990 Production Capacity 600

Product Description

Smart epoxy resin AB glue filling machine

PGB-700
Strong versatility
Multiple configuration
High production capacity
High precision


Model: PGB-700
Dimension: 1500*1100*1600mm
XYZ working area: 700*700*100mm

AB ratio: 100:100-100:10 adjustable
Movement Track: Dot/Line/Arc/Circle
Speed: 500mm/s (Movement speed) 1-12g/s (gluing out speed)
Accuracy: ±0.03mm (Repeatability) ±2% (potting) ±2% (mixing)
Program: 99pcs/more
Input pressure: 0.5MPa-0.7MPa
Viscosity: 50cps-30000cps (Glue can be heated to decrease viscosity)
Operation Method: Manual/Automatic
Meter Pump: Gear pump/Screw pump/Double cylinder plunger pump
Flow Control: Digital Input
Programming method: teaching programming
Automated control system: PLC / touch screen (programming, modification, storage, etc.)
Glue control system: AB glue suction valve to achieve independent operation of AB glue
Mixed mode: dynamic and static optional, instant mixing, easy to clean
Tank:stainless steel(40L),(25L),(10L)optional
Power supply: 220V/50Hz/1200W ( The power consumption without heater)



Glue Potting Machine PGB-700

Category: Glue Potting Machine
Brand: D&H
Model:PGB-700
Applications: capacitor, power supply, transformer, ignition coil, reverse sensor, circuit board, electronic ballast, art stickers , other electronic products where glue potting demanded.
Suitable Material: AB part glue , silicone , epoxy resin, polyurethane ...



Features

1, Glue controlling system of metering, mixing and potting.
2, Accurate metering and even mixing helps to avoid the waste of glue.
3, Dispensing size and positioning keep machine work consistent and fast.
4, Good universality makes PGB-700 machine suitable for applications of LED, electric and others glue potting needed products.
5, Easy to program and operate.
6, Tally function, non-standard mode, primer mode, level alert, filter mode, liquid display device, preventing back-flow device and other functional device.

The working principle:



Liquid A & B are kept in two tanks separately. There are two sets of metering pumps inside the machine, draining out liquids individually from tank A & B. Liquid A & B mix with each other in the mixer pipe and dispensed out according to the programmable data.
