• Model NO.：L8
• Transport Package：Wooden Box
• Specification：CE ,UL
• Trademark：ETA
• Origin：China
• HS Code：8515190000
• Production Capacity：100 Set,Month

GENERALOutside dimension5310*1353*1490mmStandard colorComputer greyWeight2150kgNumber of heating zonesUp8/bottm8Lengthof heating zones3121mmNumber of cooling zones2(built-in)Exhaust volume10M3/min*2 exhaustsStandard feature of control systemElectric supply required3phase, 380V 50/60Hz Electric power required64KWPower for warm up32KWPower consumption10KWHeating patternUp& Bottom Hot airWarming timeApprox. 30minuteTemp. setting rangeRoom temp__300degreeControl systemPLC+ ComputerTemperature control methodPID close loop control +SSR drivingTemperature control precision± 1.0degreeTemperature deviation on PCB± 1.5degreeData storageProcess data and status storage (80GB)Abnormal alarmAbnormal temperature(extra-high/extra-low temp)Board dropped alarmTower light: yellow warming: Green-normal: Red-abnormalStandard features of conveyor systemMax. width of PCBMax: 450mm(Standard)Rail Number1 Lane(standard) 2 Lane (option)Components clearanceTop/bottom clearance of PCB is 25mmConveyor heightLight → right(option: R→ L)PCB transmission agentAir-reflow=chain +mesh (Standard)Conveyor height900± 20mmConveyor speed range300~2000mm/min
