• Model NO.：HPC-2026
• Productivity：Max: 3200 PCS,H ( L< 300 Mm)
• Place of Origin：China
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Mould Life：>1, 000, 000 shots
• Customized：Customized
• Transport Package：Wooden Case:1365 Mm ( L )X1220 Mm ( W )X1890 ( H )
• Specification：SGS
• Trademark：Hiprecise
• Origin：Xiamen, China
• HS Code：8537101990
• Production Capacity：30 Sets , Month

Basic Info.

Model NO. HPC-2026 Productivity Max: 3200 PCS/H ( L< 300 Mm) Place of Origin China Precision High Precision Demoulding Automatic Heating System Electric Mould Life >1, 000, 000 shots Customized Customized Transport Package Wooden Case:1365 Mm ( L )X1220 Mm ( W )X1890 ( H ) Specification SGS Trademark Hiprecise Origin Xiamen, China HS Code 8537101990 Production Capacity 30 Sets / Month

Product Description

Wire strip crimp Fully Automatic Machine(HPC-2026)

1. Both ends crimping.

2. Applicable for home appliance and automobile harness processing.

3. Productivity: MAX: 3200 PCS/H ( L< 300 mm)

4. Adopt JapanTHK linear guide, Japan SUMITOMO precise servo reduction gears to ensure high accuracy and long life of the whole machine.

5. Adopt JapanSMC pneumatic elements, high reliability.

Touch man-machine graphics operation screen, visualized and concise.

6. Adopt Japan YOKOGAWA high-performance programmable controlling technology, Japan MITSUBISHI servo and Japan SANYO stepping controlling technology. The machine is stable, reliable and the processing accuracy is high.

7. Adopt the frequency conversion controls terminal crimping machine to accomplish power saving and low noise.

Model	HPC-2026
Cutting Length	35mm-20000mm
Stripping Length	Front end :1.0mm-11.0mm; Rear end:1.0mm-7.5mm
Cutting Accuracy	<±(0.5+0.002*L) (Depending on equipment adjustment and wire materials)
Wire Range	0.05-0.52mm² ( AWG28-AWG14)
Crimping force	1.2ton
Power	AC220V 50Hz  10A
Air Source	>0.5Mpa
Air Consumption	90NL/min
Dimensions	980mm(W)×700mm(L)×1550mm(H)
Weight	350Kg
