Automatic Coil Winding Machine (SS86X Series)
SanShine Electronics (Xiamen) Technology Co., Ltd.- Voltage:220V
- Warranty:12 Months
- Wire Size:0.02~ 0.8mm (Depends on Tension & Nozzle)
- Spread Pitch:0~ 9.999mm
- Spread Width:100mm (Max. )
- Coil Diameter:100mm (Max. )
Base Info
- Model NO.:SS861 Series
- Demoulding:Pull Core
- Condition:New
- Certification:ISO, Internal
- Automatic Grade:Automatic
- Installation:Desktop
- Driven Type:Electric
- Mould Life:300,000-1,000,000 Shots
- Function:High Precision and Steady
- Transport Package:Customs approved wood box
- Trademark:SanShine
- Origin:China
- Production Capacity:6000sets,year
Description
Overview
Detailed Photos
Automatic Coil Winding Machine (SS86X Series)
Product Description
SS-86x Series digital coil winding machine are digital programmable High-speed coil winding machine, there are four models: One spindle, two Spindles, three spindles and four spindles. It's the highest efficiency equipment.
Feature:
1. Microprocessor design, easy for program-setting.
2. Stepping motor driven by constant-current power supply, High spreading speed precise winding.
3. "Start Point" could set by key panel or with teachable function. Display Will show the position of spreading head while setting.
4. Wire spreading by nozzle type spreading head.
5. Wire passing through ceramic rollers prevent enamel from high temperature.
6. Multiple spindles winding synchronal for highest efficiency.
7. Foot-switch connection for better efficiency.
8. Winding parameters and options can be set independently for each step.
9. Memory capacity accommodates 999 steps of parameters with off-power memory retention.
0.02~ 0.8mm (Depends on Tension & Nozzle)
Spread pitch
0~ 9.999mm
Spread width
100mm (Max. )
Coil diameter
100mm (Max. )
Main motor
Brushless Motor
Spread motor
Stepping motor
Max. speed
6000rpm
Memory
999 Sequences
Power source
AC220V + 10%, 50/60 Hz
Dimension (CM)
45x67x100
50x67x100
75x67x100
100x67x100
Net weight(KG)
45
50
55
60
