Two Poles Stator Automatic Coil Winding Machine Motor Coil Winder
Shanghai Wind Automation Equipment Co., Ltd.- Warranty：12 Months
- Color：Customized
- Dimension：1050X2300X1750mm
- After-Sales Service：Engineers Avaiable to Service Overseas
- Condition：New
- Customized Service：Provided
Base Info
- Model NO.：WIND-1A-TS
- Transport Package：Wooden Case
- Specification：Middle Size
- Trademark：Wind Automation
- Origin：China
- HS Code：8479811000
- Production Capacity：100 Sets,Year
Description
Basic Info.
Model NO. WIND-1A-TS Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Two Poles Stator Automatic Coil Winding MachineMotor Coil Winder
This stator winding machine is designed for producing coil winding of two-poles stator, such as mixer motor, grinder motor, vacuum cleaner motor etc. With double working stations, this machine can synchronously wind two stators. Winding programs can be edited and stored in the touch screen memory.(1) Specifications
| Stator OD | 50-150mm |
| Stack length | 20-60mm |
| Wire diameter | 0.15-1.3mm |
| Turn number | 0-9999 |
| Pole no. | 2 poles |
| Spindle speed | 0-450 rpm |
| Air supply pressure | 5-7 Kg/cm2 |
| Voltage | AC380V 50/60Hz |
| Weight | 1200Kg |
| Dimension | 1050X2300X1750mm |
(2)Application
This stator winding machine is designed for producing coil winding of two-poles stator, such as mixer motor, grinder motor, vacuum cleaner motor etc.
(3)Operation Procedure
Fix winding tools on the stator core.
Then load the whole set on the winding area of machine.
Press Start button.
Machine will automatically do winding.
Unload the stator
