• Model NO.：BR-2-1100
• Tension：20000 N
• Centering Mode (Rectifying)：Manual , Automatic
• Manual / Automatic：0~20rpm
• Working Torque：Max 8000 N-M
• Winding Power：18.5 Kw
• Welding Machine Mode：Welding Machine Mode
• Transport Package：Standard Packing
• Specification：4700*4200*2200mm
• Trademark：Trihope
• Origin：Shanghai
• Production Capacity：30 Sets,Month

Basic Info.

Model NO. BR-2-1100 Tension 20000 N Centering Mode (Rectifying) Manual / Automatic Manual / Automatic 0~20rpm Working Torque Max 8000 N-M Winding Power 18.5 Kw Welding Machine Mode Welding Machine Mode Transport Package Standard Packing Specification 4700*4200*2200mm Trademark Trihope Origin Shanghai Production Capacity 30 Sets/Month

Product Description

Transformer 1100mm Double Layer Copper and Aluminum Foil Winding Machine
This foil winding machine is double layer foil winding machine ,apply to amorphous transformer,oil-immersed transformer,winding coil is single foil belt.Coil shape can be round, oval, square, rectangle, etc.


Product details:

BR/2-1100 foil winding machine include 1) Foil uncoiling device, 2)Winding device , 3)Layer insulation uncoiling device, 4) The main frame parts, 5)Welding device, 6)Deburring and cleaning device , 7)Cutting device , 8)The end insulation uncoiling device, etc.

Feature of  Foil winding machine:

This foil winding machine is double layer foil winding machine ,apply to amorphous transformer,oil-immersed transformer,winding coil is single foil belt.Coil shape can be round, oval, square, rectangle, etc.,

The equipment is with full function, high production efficiency, the foil belt tension by pneumatic control is convenient and reliable, adjusting by servo control is accurate ,stable and reliable, to ensure the processing quality of wire coil.

LV foil coil uses different thickness copper or aluminum foil as conductor, wide band type insulation material as layer insulation , complete winding in foil type winding machine, forming roll coil.

This equipment can also be applied to the similar coil winding of electrical industry .

The machine adopts PLC control method has the characteristics of high degree of automation and full function.

Each function of equipment provides enough support for producing the electrician foil coil which meet the requirements of specification .This machine is necessary equipment for producing such appliances parts.
