• Model NO.：KW520
• Installation：Vertical
• Driven Type：Electric
• Servo：Panasonic, Fuji
• Motor：Panasonic, Fuji
• Metering Pump：Barmag
• Cleaning method：automatic high pressure water and air
• working range：2200x1200x200mm
• mixing head：KW700, KW900
• IP：IP66
• Transport Package：EPE Simple Package
• Specification：24CBM
• Trademark：KAIWEI
• Origin：China
• HS Code：8424899990
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. KW520 Installation Vertical Driven Type Electric Servo Panasonic, Fuji Motor Panasonic, Fuji Metering Pump Barmag Cleaning method automatic high pressure water and air working range 2200x1200x200mm mixing head KW700, KW900 IP IP66 Transport Package EPE Simple Package Specification 24CBM Trademark KAIWEI Origin China HS Code 8424899990 Production Capacity 100 Sets Per Month

Product Description

KW-520  2-component foaming machine is a 2-component mixing and dosing system. It can be used to foam, glue and pot for various
Workpieces. KW-520 adopts Germany BARMAG high accurancy metering pump which can adapt low viscosity, medium viscosity and
High viscosity polymers and materials, Such as polyurethane, silicone, silicon gel, exposy resin and other reaction materials. KW-520
Can run with high stability as an independent equipment or a part of automatic production line.
2-Component Foam Machine


KW-520 has different operating modes. The standard control system is a movable cantilevered control panel with 15-inch touch screen.
After adjusting the machine and prestting the parameters, the machine will run accurately, safely and efficiently according to the technical
Setting during the production.
Control System Parameters
• Perfect combination of industrial PC and control of motion
• Real-time bus systom
• Pluggable switchpanel( aviation socket)
• 3 operating mode: Adjust/ready/automation
• Formulation management
• 3 levels password protection ((optional)
• Data backup by U disk, SI or LAN
• Accurately adjust material reaction time, feeding quantity prest, automatic cleaing and air injecting/ stirring materials by programs
• Adjust automatic material feeding by controling the pressure
• Counter and timer start automatically as the machine runs
• Monitor and digital dispaly the pressure of components
• Open interfaces
• Operating system and programs can be store in a memory card
Driver technical parameters
• Speed-control servo motor with speed and ajusting display
