SMT Desktop Leaded PCB Wave Soldering Welding Oven Tb680 (TORCH)
Termway (Beijing) Precision Technology Co., Ltd.- Condition：New
- Certification：ISO, CE
- Warranty：18 Months
- Automatic Grade：Automatic
- Installation：Desktop
- Wave Height Adjust Range：5~ 10mm
Base Info
- Model NO.：TB680
- Weight：70kg
- Dimension：840 X 540 X 380mm
- PCB Width (L× W)(mm)：200 X 270mm (Max)
- Preheating Temperature：90~130c
- Temperature Range：200~300
- Melt Time：60min
- Power Supply：220V 50Hz
- Conveyor Speed：0.5~ 2m ,Min CTV
- Spray Way：Foam
- Transport Package：by Wooden Case
- Specification：ISO9000 ISO14000
- Trademark：Torch
- Origin：Beijing
- HS Code：8479820090
- Production Capacity：10PCS,Month
Description
Model
TB680
The max power consumption
3Kw
Solder pot capacity
37Kg
PCB width (L×W)(mm)
200 X 270mm (Max)
Temperature range
200~300
Preheating temperature
90~130
Wave height adjust range
5~ 10mm
Melt time
60min
Spray work mode
froth
Power supply
220v 50Hz
Conveyor speed
0.5~ 2m /min CTV
Dimension
840 X 540 X 380mm
Weight
70Kg
