Torch Desktop Mini 12heating Zone Reflow Oven R350
Termway (Beijing) Precision Technology Co., Ltd.- Condition：New
- Certification：ISO, CE
- Warranty：24 Months
- Automatic Grade：Automatic
- Installation：Vertical
- Max PCB Size：600mm*350mm
Base Info
- Model NO.：R350
- Temperature Accuracy：Within2 Degree
- Temperature Uniformity：Within 5 Degree
- Rated Voltage：AC Single-Phase 220V, 50Hz
- Max Power：7.8kw
- Average Power：2.5kw
- Dimension：1500* 700* 520mm
- Heating Zone：12heating Zone
- Plate-Heater：Ceramic
- Transport Package：Plywood with Foam Inside
- Specification：CE
- Trademark：TORCH
- Origin：Beijing China
- HS Code：851410900
- Production Capacity：1000 Sets Per Year
Description
Model
R350
Temperature zone
up and down total12groups temperature zone + 4 groups inline testing
Controlling temperature system
computer control system, SSR without touch point output
Temperature accuracy
± 2 °C
Temperature uniformity
within 5 °C
Temperature range
room temperature -360 °C
Heat source
dark infrared ray + hot air convection
Circuit board welding size
600mm *350mm
Welding time
3min ± 1min
Temperature curve
can be set by requirements,meanwhile real time test and analyst welded circuit board temperature
Cooling system
wind cooling,can use air cooler to reduce temperature rapidly
Rated voltage
AC single-phase 220 v; 50 hz
Max power
7.8KW average power: 2.5kw
Weight
150 kg
Size
1500* 700* 520mm
