Copper Plastic Electrical Cable Wire Winding Twisting Cutting Extrusion Extruder Making Twister Coiling Machine

Kunshan Fuchuan Electrical and Mechanical Co., Ltd.
  • Driven Type：Electric
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Mould Life：>1,000,000 Shots

Base Info

  • Model NO.：FC-1000B-1
  • Type：High-speed Stranding Machine
  • Machine Color：Sky Blue
  • Single Wire Dia：0.3-1.7mm
  • Core Wire Dia：2.0-5.0mm
  • Magnetic Powder Clutch：20kgf
  • Max Rotating Speed：1000rpm
  • Operation Mode：Touch Screen
  • Tinned Wire：Above 7PCS
  • Area：Silver Jacketed Wire
  • Transport Package：Customery Packing
  • Specification：ISO9001
  • Trademark：Fuchuan
  • Origin：Jiangsu Kunshan
  • HS Code：8479111000
  • Production Capacity：50sets,Month

Description

Equipment modelsFC-1000BTwisting usageIt is applied to the twisting of above seven pcs of bare copper wires, tinned wires, silver jacketed wires ,enameled wires, and double twisting for core wires.Single wire dia(mm)φ0.30-φ1.7Stranding section area (mm²)6.0-35.0 Core wire single wire diaφ2.0-φ5.0Core wire stranding outer diaφ4.0-φ10Pitch(mm)35-200(12zones)Direction of layOptional for right or leftTake up bobbin Outer dia*bore*outer widthφ1000*φ80*750Max rotating speed1000(2000twist)Main motor power18.5KWInverter power18.5KWTension control methodTouch screen+ PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbinMagnetic powder clutch20kgfProtectionMachine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived.Brake modeElectromagnetic brakeTraversing methodRolling ring drive units, winding pitch and breadth are adjustableOperation modeTouch screen operationDimension(mm)4000L*2200W*2100HCopper Plastic Electrical Cable Wire Winding Twisting Cutting Extrusion Extruder Making Twister Coiling Machine
