• Model NO.：FC-70+45
• Heating System：Electric
• Function：High Temperature Resistance
• Mould Life：300,000-1,000,000 Shots
• Automatic Grade：Automatic
• Customized：Customized
• Transport Package：Standard Packing
• Specification：21m L*2.0m W*2.2m H
• Trademark：Fuchuan
• Origin：China
• HS Code：8479111000
• Production Capacity：27sets,Per Month

Basic Info.

Model NO. FC-70+45 Heating System Electric Function High Temperature Resistance Mould Life 300,000-1,000,000 Shots Automatic Grade Automatic Customized Customized Transport Package Standard Packing Specification 21m L*2.0m W*2.2m H Trademark Fuchuan Origin China HS Code 8479111000 Production Capacity 27sets/Per Month

Product Description

φ70extruder technical specifications(touch screen control)

1. Fit for material of PVC for electrical wire insulating-sheathing extrusion.
2. Machine direction :right hand machine or left hand machine
3. Line axis height 1000mm;
4. Inlet wire diameter:φ0.5mm-φ5.0mm; Finished wire diameter:φ1.5-φ7.0mm;
5. Linear speed:350m/min(according to wire)
6. Machine color:Ral5015 sky blue
7. Power in customer's area:3P/380V/50HZ
8. Main components of machine: pay off; main extruder; wire accumulator, meter measure device; electrical cabinet and so on.
9.
