0.38-1.7mm Bare Copper Wire High Speed Twisting Machine and Double Twister Machine

Kunshan Fuchuan Electrical and Mechanical Co., Ltd.
  • After-sales Service：12months
  • Driven Type：Electric
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic

Base Info

  • Model NO.：FC-300B,400B,500B,650B,800B,1000B,1250B
  • Mould Life：300,000-1,000,000 Shots
  • Type：Double Stranding Machine
  • Single Wire Dia：0.38-1.7mm
  • Core Wire Single Wire Dia：1.0-4.0mm
  • Fit for Take up Bobbin：Diameter 800mm
  • Stranding Section Area：1.0-16mm2
  • Main Motor Power：15kw
  • Magnetic Tension Clutch：10kgf
  • Max Rotating Speed：1500rpm
  • Pitch Area：23-147
  • Twisting Usage：Double Twist
  • Transport Package：Standard Packing
  • Specification：4600L*2000W*2000H mm
  • Trademark：fuchuan
  • Origin：China
  • HS Code：8479811000
  • Production Capacity：50sets,Month

Description

Equipment modelsFC-800BTwisting usageIt is applied to the twisting of aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.Single wire dia(mm)φ0.38-φ1.70Stranding section area (mm²)1.0-16Core wire single wire diaφ1.0-φ4.0Core wire stranding outer diaφ2.0-φ8.0Pitch(mm)23-147(20zones)Direction of layOptional for right or leftOuter dia*bore*outer widthφ800*φ80*600Max rotating speed1500(3000twist)Main motor power15KWInverter power15KWTension control methodTouch screen +PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbinMagnetic powder clutch10kgfProtectionMachine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived.Brake modeElectromagnetic brakeTraversing methodRolling ring drive units, winding pitch and breadth are adjustableOperation modeTouch screen operationDimension(mm)4600L*2000W*2000H0.38-1.7mm Bare Copper Wire High Speed Twisting Machine and Double Twister Machine
