High Precision Cable Machinery Equipment Twister Laying-up Machine

Hejian Bao Hong Electrical Machinery Co., Ltd.
  • After-sales Service：One Year Warranty
  • Driven Type：Electric
  • Condition：New
  • Certification：ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic

Base Info

  • Model NO.：1600 , 1+1+3
  • Mould Life：>1,000,000 Shots
  • Type：To Back Stranding Machine
  • Material：Metal
  • Colour：as Required
  • Wire Diameter Specification：8-25mm
  • Cage Speed：28 Rpm
  • Stranding Pitch：420-3500 mm
  • Traction Wheel Diameter：2000 mm
  • Pay-off Bobbin in Cage：Pn1600
  • Central Pay-off Bobbin：Pn1600
  • Take-up Bobbin：Pn3150
  • Central Height：1100 mm
  • Transport Package：Seaworthy Packing
  • Specification：1600 , 1+1+3
  • Trademark：BH
  • Origin：Hejian, Hebei, China
  • HS Code：8479400000
  • Production Capacity：15 Sets,Month

Description

Model (Laying-up Machine)CLY-630/3+3CLY-800/3+3CLY -1000/3+1+1CLY -1250/3+1+1CLY -1600/3+1+1Diameter of single wireφ5-10 mmφ5-12 mmφ8-20mmφ8-25 mmφ10-35 mmMaximum stranded conductor ODφ30 mmφ40 mmφ63 mmφ70 mmφ80 mmStranding Pitch50-800 mm95-1500 mm200-2000 mm420-3500 mm550-5176 mmCapstanCapstan Wheel Diameter1000 mm1200 mm1800 mm2000 mm2500 mmMaximum Haul-off Force10 T12 T15 T20 T25 TMotor Power18.5 KW22 KW30 KW37 KW55 KWBobbin Size630 mm800 mm1000 mm1250 mm1600 mmTake-up Bobbin1600 mm1800 mm2000 mm2500 mm3150 mmMaximum Haul-off Linear Speed60 m/min60 m/min34 m/min28 m/min21 m/minCentral Height1000 mm1000 mm1000 mm1000 mm1000 mm
3.Photo
High Precision Cable Machinery Equipment Twister Laying-up Machine
High Precision Cable Machinery Equipment Twister Laying-up Machine
High Precision Cable Machinery Equipment Twister Laying-up Machine
High Precision Cable Machinery Equipment Twister Laying-up Machine
High Precision Cable Machinery Equipment Twister Laying-up Machine
