• Model NO.：A6
• Heating System：Electric
• Function：High Temperature Resistance
• Mould Life：>1,000,000 Shots
• Customized：Non-Customized
• Transport Package：Wooden Box
• Specification：3500*750*1320mm
• Trademark：Jaguar
• Origin：Shenzhen
• HS Code：8501109101
• Production Capacity：25sets Per Week

JAGUAR A6

Heating SystemNumber of heating zonesUP 6/BOTTOM6Length of heating zones2400MMHeating modeUp:hot air; bottom: IRCooling ModeForce air


Conveyor SystemMax. Width of PCB350mmMesh belt width400mmTransmission DirectionL→R(or R→L)Transmission Net Height880±20mmTransmission typeMeshConveyor speed0-1000mm/minFixed rail sideFront rail fixed(option:rear rail fixed)







Control systemPower supply5 line 3 phase 380V 50/60HzTotal power28kwStarting power24kwNormal power consumption4KWWarming timeAbout 20 minsTemp. setting rangeRoom temperature-300ºCTemp. control methodPID close loop control & SSR drivingTemp. control precision±1ºCTemp. deviation on PCB±2ºCData storageProcess Data and status storage
(80 GB)(machine with PC)Nozzle plateAluminum Alloy PlateAbnormal AlarmAbnormal temp. (extra-high/extra-low temp.)Board dropped alarmTower light:yellow-warming, Green-normal,  Red-abnormal
GeneralDimension(L*W*H)3500×700×1320mmWeight600KGColorComputer gray




FAQ:
 1) This is the first time I use this kind of machine, is it easy to operate?
 There is english manual or guide video that show you how to use machine.
  If you still have any question, please contact us by e-mail / skype/ phone /trademanager online service.
 2) If machine have any problem after I receive it, how can I do ?
 Free parts send to you in machine warranty period.
If the part is less than 0.5KG, we pay the postage.
 If it exceeds 0.5KG, you need to pay the postage.
 3) MOQ ?
 1 set machine, mixed order is also welcomed.
 4) How can I buy this machine from you? ( Very easy and flexible !)
  A. Consult us about this product on line or by e-mail.
 B. Negotiate and confirm the final price , shipping , payment methods and other terms.
 C. Send you the proforma invoice and confirm your order.
 D. Make the payment according to the method put on proforma invoice.
 E. We prepare for your order in terms of the proforma invoice after confirming your full payment.
 And 100% quality check before shipping.
 F.Send your order by air or by sea.
 5)Why choose us ?
 A. Gold supplier on MIC !
 B. Trade assurance to US$54,000 !
 C. Best price & Best shipping & Best service !
