• Model NO.：HH-50
• Wire Spec：2-5 mm
• Wire Speed：Max: 300meters,Min
• Extrusion Capacity：150 Kg,H
• Bobbin Size：400-600 mm
• Motor：Siemens
• Inventor：Yaskawa
• Main Power：150 Kw
• Material：PE, PVC
• Voltage：380V or Customized
• L/D of Screw：25:1
• Transport Package：Plastic Packing
• Specification：35*20m
• Trademark：hooha
• Origin：Donguan, China
• HS Code：8479400000
• Production Capacity：3 Set,Month

No.ItemsQuantity1500 Bunching machine1 set2Pay off stand multi-core copper wire1 set


Parameters:

No.ItemsValue1Single wire diameterØ0.08mm-Ø0.30mm2Stranding area0.3mm2-2.5 mm23Stranded wire length calculationHow many meters per minute = twisting distance *2/1000* twisting bow speed per minute4Twisting pitch5.66 - 39.37mm5Rotation speed of arched bandMax: 2200RPM.6Spindle lubricationUse manual grease gun to inject oil




2. HH-E-PLC 50 Extrusion Machine

Application:
This equipment is suitable for outer surface extrusion of wires and cables with insulation materials such as PVC/PE.

Components:

No.ItemsFeatures1400-630 motorized pay-off stand1 set25-wheel Straightening device1 set350 Host extruder1 set450 Adjustable extrusion head1 set5Automatic drying and feeding machine1 set6PLC electric control box1 set71.5m Movable water tank with cover1 set8Diameter tester1 set98m Fixed water tank with cover and leak-proof1 set1010 m Slide rail type + anode guide wheel storage rack1 set11410mm tractor1 set12Meter counter1 set13High frequency spark tester1 set14400-630 Double-head shaftless motorized take-up stand1 set15Display board1 set16Accessories1 set


Parameters:


No.ItemsFeatures1Inlet Wire Diameter0.5~3 mm2Finished Wire Diameter1~5 mm3Cross Sectional Area0.5~2.5 square mm4Extrusion SpeedMax 500 m/min5Extrusion Capacity80 kg/h6Installed Capacity45 kva7Voltage380KV, can be customized8Weight3500 kg9Measurement (L*W*H)20*3*3 m10Workers recommendation3 workers




3. 630 Cantilever Single Twisting Machine
Application:
It is suitable for the twisting and synchronous winding of insulated core wires such as USB cable, electrical cable, communication cable and data cable etc. This single twisting machine is widely used in various types of wires and cables production process.

Components:

No.ItemsQuantity18 Heads Horizontal tension pay off stand1 Set2PLC Siemens electric control box1 Set3Wire collection device1 Set4Wrapping machine1 Set5630 Cantilever single twisting main machine1 Set


Parameters:

Motor

Drive (Main machine) motor: AC 380V 10 HP
Capstan motor: AC 380V 5 HP
Linkage wrapping machine motor: AC 380V 2 HP



Inverter

Drive (Main machine):10 HP
Capstan: 5 HP
Linkage wrapping machine:2 HP



Electric control box

PLC Systems: SIEMENS brand, Man-machine interface complete computer control
Tickle touch screen: Easy to operate
Human Interface: SIEMENS




4. PLC 70 Extrusion Machine

Application:
This equipment is suitable for outer surface extrusion of wires and cables with insulation materials such as PVC/PE.

Components:

No.ItemsFeatures1Inlet Wire Diameter1~4mm2Finished Wire Diameter2~8 mm3Cross Sectional Area1~6 square mm4Extrusion SpeedMax 400 m/min5Extrusion Capacity140 kg/h6Installed Capacity55 kva7Voltage380KV, can be customized8Weight4000 kg9Measurement (L*W*H)24*3.5*3.5 m



What  IS YOUR SERVICE TO BUILD CUSTOMER'S PLANT ?

Pre-sales
1.Experienced engineer team provides customized solutions and equipment layout drawing service
2.Professional engineer team provides overseas face-to-face service to offer advice and solution
3.Advanced trading system guarantees high-efficient communication
4.High-performance team including experienced salesmen,order supervisors, shipping managers, finance managers,wire and cable engineers would give you more detailed andaccurate consultation service

Mid-sale
1.Professional follow-up system ensures high-quality service including live production video shooting,etc
2.Quality control system with professional engineers ensures project goes smoothly
3.Quality checking service with a test report before delivery ensures products quality

After-sale
1.Overseas on-site installation guidance and technical support including previous testing, operation instruction and talent training
2.Free lifetime online consultation service
3.Long-time maintenance, reconstruction and upgrade services of the wire and cable equipment
4.Additional service support, such as raw material or accessories supply and suggestions, etc.
