Lead Free Wave Solder Machine for Electronics with Ce Approve
Shenzhen Jaguar Automation Equipment Co., Ltd.- Condition：New
- Certification：CCC, RoHS, ISO, CE
- Warranty：12 Months
- Automatic Grade：Automatic
- Item：SMT Wave Soldering Machine
- Number of Heating Zones：2
Base Info
- Model NO.：N300
- Length of Heating Zones：1200mm
- Weight：1000kg
- Power：9-11kw
- Spray Method：SMC&Nozzle
- Flux Capacity：Max 3.2L
- Preheating Zone Quanlity：2 Zone
- Preheating Length：800m
- Solder Volume：220kg
- PCB Conveyor Height：750
- Transport Package：Wooden Box
- Specification：CE
- Trademark：Jaguar
- Origin：China Shenzhen
- HS Code：85151900
- Production Capacity：100PCS,Month
Description
Model No.
JAGUAR N300
Number of heating zones
3
Length of heating zones
1600mm
Body size
3300(L)*1400(W)*1560(H)
Outside dimension
4100(L)*1400(W)*1560(H)
Weight
1100KG
Total/running power
24KW/6-8KW
Air supply
0.5MPa
Preheating method
Micro air
Preheating power
220V 8KW
Control method
PC +PLC
Range of temp. control
Room temperature---300ºC
Preheating time
About 10-15mins for setting 150ºC
Solder type
Lead-free
Solder pot capacity
320KG
Solder pot temperature
300ºC
Solder power
380V 12KW
Solder temp. control method
PID&SSR
Wave crest drive power
1KW 220V
Warm-up time of solder
About 120mins for setting 250ºC
PCB width
30-350mm
Conveyor speed
300-2000mm/min
Conveyor direction
L→R (R→L optional)
Conveyor angle
4-7 º
Flux pressure/capacity
3-5 bar/6.5L
Finger material
Ti
Finger type
Dual hook
Solder pot heater
Cast iron
Introduction:
1.Efficient, energy-saving, lead-free, environment-friendly, safe and brand-new design, simple operation, convenient maintenance.
2.Automatic power system, frequency converter control, automatic board input system.
3.Flux sprays system using scanning spray nozzle, Japanese nozzles and rodless pneumatic cylinders and PLC control, accurate and reliable.
4. Preheating system uses three independent temperature control so that ensure the excellent heat preservation, temperature uniformity, temperature difference no more than ±2ºC.
5.Special alloy transportation chain claws, non-stick tin and ensures the quality of welding PCB board.
6.Tin stove adopts imported high frequency conversion motor independent control, stable performance.
7.Lead-free solder furnace with independent design, environmental protection and safety,
easy to clean.
8.Tin stove preheating furnace uses high-speed PID and 2 independent infrared heating(IR heating) control.
9.Time can be controlled, we can preset switch functions, tin stove can heat within 90 minutes.
10.With black box memory function, the machine can always store the production management records, improve work efficiency.
11.Automatic claw cleaning function ensure the cleanliness of claws.
12.Reasonable design and sensitive fault security alarm system ensure the stable performance and operators' safety.
