• Model NO.：T1200LED, LED600, TN380C
• Type：High-speed Chip Mounter
• Weight：350kg
• Component Available：0603and Above SMD Component and LED
• Typical Mounting Speed：6000-6500 Cph
• Mount Head：2 PCS
• Dimension：2600*680*1500mm
• Max Circuit Board Size：1200*350mm
• Transport Package：Wooden Package, 1 Set ,PC, About 400kg
• Specification：CE Rosh
• Trademark：Termway
• Origin：Beijing, China
• HS Code：8479896200
• Production Capacity：50set,Year

Heating part parameterHeating zone8 heating zones(8 upper, 8cover)+1 cooling zoneHeating methodFull forced Hot air heatingWarm-up time25minCooling zone1 zone, (1up/1 below)Cooling methodtransverse flow vortex centrifuge blowerBuilt-in automatic relay heating systemTo prevent over-pressure damage controller or motor when start up and to prevent component damage when welding.  Transmission parameterPCB Board width≤ 300mmPCB conveyor Height900± 20mmconveyor directionL→ R or R→ LConveyor MaterialStainless steelChain-driven Mesh belt conveyorNet belt and chain-driven transmissionMesh belt width300mmConveyor speed0-1600mm/min adjustableControl part parameterPower supply380V (3 ph, 4 wires) 50/60HzMax Power42KWNormal working power23KWWarm-up time≤ 30minControl systemPLC+ Torch module temp control system+ IPCRange of temperature controlRoom Temperature-360 CTemperature controlAdvanced Intelligent micro computer PID temperature control automatically in each zone + SSR non-contact outputPrecision of temperature control± 2 CTemperature distributing error± 2 C  Machine Body Parameter  Net Weight860kgDimension(L× W× H )(mm)3500× 900× 1390mm
