• Model NO.：SR-8300
• Cutting Length：1-99999.9mm
• Stripping Length of Outer Sheath：10-120mm
• Stripping Length of Inner Skin：Front 1-120mm, End 1-80mm
• Wire Cross Section：0.1-30mm2
• Wire Outer Diameter：2-15mm
• Transport Package：Plywood Case
• Specification：700*500*500mm
• Trademark：Sinrad
• Origin：China
• HS Code：8479899990
• Production Capacity：100 Sets,Month

Specification: Features:

Function: Automatically cutting and stripping outer jaket and inner skin of multi-core cable.

(1)Blade: High-quality imported high-speed steel.

(2)Capacity: 2300pcs/h, depends on the wire length and size.

(3)Drive method: 16-wheel drive (silent hybrid stepper motor, servo tool holder).

(4)Feeding:  Belt-driven feed, no embossing and scratches on the cable.

(5)Special cables, special requirements can be customized.



Pictures:



Contact:

 FAQ:

1 Price terms

The price is based on EWX/FOB, if you request CFR or CIF, please give us your delivery port, and we will give you CFR price or CIF price for reference.

2 Can I send samples to check the machine quality.

Yes, welcome to send us samples. We would be pleased to show you trial testing base on your samples.

3 How to learn the machine?

1) Offer free technology learning support in our factory

2) Provide detail user manual with detail video illustration

3) Support engineer service at site if clients asking for

4 How about the lead time and delivery time of order?

Standard model, can be ship out within 3~7days after confirmed order and deposit.

Customized model, normally lead time is 10~30 days, after confirmed all order detail deposit and got samples.

Company info:
Sinrad Technology Co.,Ltd, specialized in automation machine, customizing and manufacturing cable processing(cutting, striping, twisting, crimping, soldering, housing inserting, winding, binding, testing, etc.) machine, automatic soldering machine, intelligent soldering machine, and other production equipment.
