- Model NO.:1246,1860
- Wire Spec:1-4.5 mm
- Wire Speed:Max: 300meters,Min
- Extrusion Capacity:140 Kg,H
- Bobbin Size:500-800 mm
- Motor:Siemens
- Inventor:Yaskawa
- Main Power:85 Kw
- Material:PE, PVC
- Voltage:380V or Customized
- L/D of Screw:25:1
- Transport Package:Plastic Packing
- Specification:30*20m
- Trademark:hooha
- Origin:Donguan, China
- HS Code:8479400000
- Production Capacity:3 Set,Month
No. | Items | Quantity |
1 | 650 Bunching machine | 1 set |
2 | Pay off stand multi-core copper wire | 1 set |
Parameters:
Model | Right-hand model. The operator faces its front and the wires enter it from its right side |
Rotation speed of arched band | Max: 1800RPM. The bow strap is a guide wheel bow strap |
Twisting pitch | 15-60.24mm (can be adjusted appropriately according to customer needs), manual gear change twisting pitch |
Stranded wire length calculation | How many meters per minute = twisting distance *2/1000* twisting bow speed per minute |
Twisting direction | Arbitrary selection of left and right twisting direction |
Single wire diameter | Ø0.16mm-Ø1.0mm |
Stranding area | 0.4 mm2-5.5 mm2 |
2. HH-E-PLC 70 Extrusion Machine
Application:
This equipment is suitable for outer surface extrusion of wires and cables with insulation materials such as PVC/PE.
Parameters:
No. | Items | Features |
1 | Inlet Wire Diameter | 1~4mm |
2 | Finished Wire Diameter | 2~8 mm |
3 | Cross Sectional Area | 1~6 square mm |
4 | Extrusion Speed | Max 400 m/min |
5 | Extrusion Capacity | 140 kg/h |
6 | Installed Capacity | 55 kva |
7 | Voltage | 380KV, can be customized |
8 | Weight | 4000 kg |
9 | Measurement (L*W*H) | 24*3.5*3.5 m |
3. HH-P-1246 Automatic Coiling and Wrapping Machine
Application
This equipment is suitable for cable automatic coiling and wrapping, which would be packaged into a coil and can be connected to the cable extrusion machine for linkage use.
Main parameters
Coiling Speed | 800 RPM |
Coiling Size | Outside diameter is 200-460mm, height is 50-120mm, Inner diameter is 140-220mm |
Applicable Wire Range | 1-12mm |
Power Supply | AC 380 V, three-phase, 50 HZ or customized |
Operation Direction | Left or right side(Can be customized) |
Packaged Coil Weight | MAX 35 kg |
Features
1 | Automatic packaging, wrapping and labeling |
2 | Packing label capacity 7 times more than manual |
3 | 200m per coil and coiling speed 4 times more than manual |
4 | Can be directly connected to the extrusion machine |
5 | Servo motor flat cable system, perfect packing |
6 | Automatic warning system, easy control of the operation |
7 | 99 types of the coiling storage and can change as you like |
8 | Touch screen man-machine interface operation, all circuit control adopt microcomputer programmable controller |
9 | Cable row system adopt servo motor wiring system, the speed as the same as the main machine |
10 | The meter count is close to the accuracy of 0.01,forecast slow down the speed, automatic coiling renew. One coil can be set and close to 0.2% accuracy |
11 | The machine PLC contacts with power frequency spark machine for the spark of BV line detection, can automatic spark breakdown point or artificial mark continue knitting function or automatic increase 5 meters length into a circle |
12 | The machine PLC contacts with caliper gauge. Diameter is not up to standard can be automatically eliminate waste line or artificial marking after continue to function |
