• Model NO.：35,45,65
• Wire Spec：3-10 mm
• Wire Speed：Max: 200meters,Min
• Extrusion Capacity：280 Kg,H
• Bobbin Size：800-1600mm
• Motor：Siemens
• Inventor：Yaskawa
• Main Power：85 Kw
• Material：PE, PVC
• Voltage：380V or Customized
• L/D of Screw：25:1
• Transport Package：Plastic Packing
• Specification：30*25m
• Trademark：hooha
• Origin：Donguan, China
• HS Code：8479400000
• Production Capacity：3 Set,Month

No.ItemsQuantity1500 Bunching machine1 set2Pay off stand multi-core copper wire1 set



Parameters:

No.ItemsValue1Single wire diameterØ0.08mm-Ø0.30mm2Stranding area0.3mm2-2.5 mm23Stranded wire length calculationHow many meters per minute = twisting distance *2/1000* twisting bow speed per minute4Twisting pitch5.66 - 39.37mm5Rotation speed of arched bandMax: 2200RPM.6Spindle lubricationUse manual grease gun to inject oil





2. HH-E-35 Teflon Cable Extrusion Machine



Application:

This equipment is suitable for outer surface extrusion of Teflon wires and cables with insulation materials such as FEP, FPA, ETFE, PVDF.



Components:

No.ItemsFeatures1400-630 motorized pay-off stand1 set25-wheel Straightening device1 set3automatic sensor preheater1 set435 Teflon extruder1 set5U7 non-adjustable head1 set6Automatic drying and feeding machine1 set7PLC Electric control box1 set81.5m Movable water tank with cover1 set9Diameter tester1 set108m Fixed water tank1 set1110 m Slide rail type + anode guide wheel storage rack1 set12Dual-wheel capstan1 set13Meter counter1 set14High frequency spark tester1 set15400-630 Double-head take-up machine1 set16Spare parts



Parameters:

No.ItemsFeatures1Inlet Wire Diameter0.3~2 mm2Finished Wire Diameter0.5~3 mm3Cross Sectional Area0.5~2.5 square mm4Extrusion SpeedMax 150 m/min5Extrusion Capacity50 kg/h6Installed Capacity60 kva7Voltage380KV, can be customized8Weight3500 kg9Measurement (L*W*H)23*3*3 m10Workers recommendation3 workers
