SMT Torch Brand Hot Selling Desktop Leadfree Reflow Soldering Oven T200c
Termway (Beijing) Precision Technology Co., Ltd.- Condition：New
- Certification：CCC, ISO, CE
- Warranty：24 Months
- Automatic Grade：Semiautomatic
- Installation：Desktop
- Welding Max PCB Size：360mm*230mm (Less Than A4)
Base Info
- Model NO.：T200C,T200N
- Temperature-Zone Numbers：Single-Zone and Multi-Segment
- Temperature Control System：PC Control System, SSR Non-Contact Output.
- Temperature Range：Room-Temperature -360 Degree
- Heating Supply：Infrared Ray + Hot Air Convection
- Welding Time：3min±1min
- Cooling System：Transverse Flow Equal Cooling
- Rated Voltage：AC Single-Phase, 220V;50Hz
- Rated Power：3.8kw
- Dimension：Length*Width*Height 700*460*310mm
- Transport Package：Wooden Case
- Specification：CE ISO SGS
- Trademark：Torch
- Origin：Beijing
- HS Code：8514109000
- Production Capacity：100 Sets,Month
Description
Item
Parameter
Temperature control segment
40 segment .The segment can be set in computer according to the actual requirement.
Temperature-zone numbers
Single-zone and multi-segment
Temperature control system
PC control system ,SSR non-contact output.
Temperature accuracy
±2ºC
Warm-up time
3min
Temperature range
Room-temperature -360 ºC
Heating supply
Infrared ray + Hot air convection
Effective working table area
360mm * 230mm (less than A4)
Welding time
3min±1min
Temperature curve
It can be set ,adjusted and tested according to the actual requirement .
Cooling system
Transverse flow equal cooling
Rated voltage
AC single-phase ,220V;50Hz
Rated power
3.8KW
Mean power
1.6kw
Weight
39kg
Dimension
Length*width*height 700*460*310mm
