• Model NO.：HH-50MM,70MM,80,90,120MM
• MOQ：1 Set
• After Service：Overseas Engineer Send
• Transport Package：PE and Paper Box Package
• Specification：CE ISO SGS
• Trademark：HOOHA
• Origin：Dongguan
• HS Code：8479400000
• Production Capacity：5 Sets,Month

Team of HOOHA ServiceNameeducationPositionMainly responsible for projectSpecializing in project Industry working history
( year )zanyang XiecollegeGeneral EngineerThe total project design and planning power cable machine15xioahua HucollegeVis general engineerThe total project design and planning net cable,data cable machine10Chnaghong ChengcollegeEngineerDrawings and after-sales serviceTeflon,Optical fiber cable machine25xiuwu ChencollegeGeneral EngineerThe total project design and planning copper drawing machine15lixin YuancollegeEngineerThe project design and planning coppwer wire making technical16zhenghai Qiucollegecable engineerAfter servicecable making and cable factory management servie15jinxin LiucollegeMarketing engineerAfter serviceelectrical engineer7xingguo TangHigh schoolElectrical engineerAfter serviceelectrical engineer10changqiang LiHigh schoolMaintain engineerAfter servicemachina maintain and install service10haipin LiUniversityEngineering director Marketing and salesproject consulting 8sen YangUniversityEngineering translatorMarketing and salesproject consulting 5

Technique Specifications:

Line data:
- Process material: PVC/XLPE
- Process solution: single layer/ color stripping
- Conductor section: 0.75mm2to 10mm2 (single core)
                   Or up to 4 X 6 mm2multi core cable
- Insulation thickness: 0.5mm---1.5mm
- Size after insulation: 1.5mm---15mm
- Linear speed: Max. 450m/min (based on the cable diameter)
- Line axis height: 1000mm
- Machine color: Based on customer's requirement
- Machine direction: Based on customer's requirement
- Power: 3P/ 380V / 50Hz
- Total line length: about 30 m

Consisting Components:
1,double-shaft pay-off rack
2,straightener platform
3,main extruder
4,automatic dryer and hopper
5,electric apparatus main control cabinet
6,Double layer movable trough
7,laser diameter gauge or Digital Diameter controller
8,high speed printing machine
9,double-wheels capstan
10,Meter counter
11,horizontal type wire-accumulator
12,power frequency sparker
13,double-shaft take-up machine
  HOOHA   Performance tableItemConductor sectionInsalution thicknessCable diameterProduction speedUnitemm2mmmmm/minkm/hr10.750.62.345027210.62.54502731.50.62.84502742.50.73.245027540.83.937022660.84.43201971015.72501582 X 1.51.27.61307.893 X 2.51.29.21106.6104 X 41.211.5905.4114 X 61.212.5804.8
Optional:

1.Different take-up machine etc.
2.Flyer pay-off or other pay off machine.
3.Taiwan or Swiss brand crosshead.
4.Copper pre-heater.
5.Talc applicator.
6.Different brand Laser diameter gauge.
7.Coiler on line




4.Afterservice
1).Delivery dates: 45 days
2).Payment: TT or L/C
3).Packing: Wood packing and PE plastic packing ensure the goods safety on the transportation.
4). Install and training service: 2 professional engineers who has over 5 years overseas install and cable manufacture training experience.
5) after service phone number online

5.Contact information:

Http//:hoohaco.en.made-in-china.com
Add:No. Beice District, Humen Town,
Dongguan  City, Guangdong Province,China

6.Where are we:

Hongkong airport to Humen by boat 2 hours
Guangzhou airport to Humen by car 2 hours
Shenzhen airport to Humen by car 1 hour
Guangzhou South high speed train station to Humen 20 minutes
Shenzhen North high speed train station to Humen 20 minutes
