• Model NO.：WL-BE,BJE,BJE2
• Stripping Length：0.1-100mm
• Cutting Length：1-100000mm
• Max. Stripping Layers：9 Layers
• Weight：24kg
• Power Supply：110V,220V,50Hz
• Transport Package：Wooden Case Package
• Specification：600x185x280 mm
• Trademark：Dimension
• Origin：Kunshan City
• HS Code：8479811000
• Production Capacity：10000

Basic Info.

Model NO. WL-BE/BJE/BJE2 Stripping Length 0.1-100mm Cutting Length 1-100000mm Max. Stripping Layers 9 Layers Weight 24kg Power Supply 110V/220V/50Hz Transport Package Wooden Case Package Specification 600x185x280 mm Trademark Dimension Origin Kunshan City HS Code 8479811000 Production Capacity 10000

Product Description

Semi automatic cable wire stripping wire cable stripper machine

Product Description:The WL-BPX2 is specially used for flat cable stripping, widest 12P. Processing methods include cutting, stripping and splitting wire. Widely used in wire harness processing industry for automotive electrical appliances, instrumentation, lamps,household appliances, etc. 1. With splitting wire function 2. Suitable for different size flat cable, the flat catheter size can be customized 3. Length can be set in a large range 4. Simple operation and convenient maintenance 5. Fast speed, high precision and stable performanceFeatures:
1.  Chinese and English switching display
2.  The key operation, convenient and quick, Can stay in the middle of 34mm glue,
3.  Make both ends semi-stripping and twisting.
4.  Easy and fast, ultra-high precision, while compatible with ordinary wire machine function, improve production efficiency.

Specification:

Model	WL-BE	WL-BJE	WL-BJE2
Type	thick wire 8sq mm	thick wire 8sq mm	BV single stock, 10 square thick wire
Input Voltage	AC220/ 50HZ	AC220/ 50HZ	AC220/ 50HZ
Power	300W	300W	500W
Display method	Full Chinese LCD display	English/Chinese LCD	English/Chinese LCD
Cutting Length	1mm~9999mm	1~9999mm	1~100000mm
Stripping length	head0-35  tail0-15	Head0-50   tail0-50	Head 0-50          tail 0-50
Cutting Tolerances	± (0.002xL)	± (0.002xL)mm	± (0.0001xL)
Middle stripping                       cutting section	11	11	16
Available wire size	0.1~8mm2	0.1~8mm2	0.2-10 mm2
OD of catheter	¢10	¢10	¢13
Applicable wire	PVC, Teflon, glass wire etc	PVC, Teflon, glass wire etc	PVC, Teflon, glass wire,,multi-strand steel wire
Tool material	hard tungsten steel (optional)	Imported high speed steel	Imported high speed steel
Stripping speed	3000-5000	3000-5000	4000-7000
Drive method	four-wheel drive	four-wheel drive	four-wheel drive
Weight	34 kg	34 kg	34 kg
Dimension	54*51*40 cm	54*51*40 cm	54*53*41 cm





Features:

1.  Chinese and English switching display

2.  The key operation, convenient and quick, Can stay in the middle of 34mm glue,
3.  Make both ends semi-stripping and twisting.

4.  Easy and fast, ultra-high precision, while compatible with ordinary wire machine function, improve production efficiency.

Processing Capabilities: Cutting to length, Full strip,

Half strip, precision cut

Sample: cut and strip wire automatically
