• Model NO.：ADSGW22-2
• Max.Winding Speed：2200rpm
• Wire Spacing：Proportional Linkage
• Supply Voltage：AC 220V(50Hz)
• Mechanical Dimensions：720×950×1300mm
• Weight：180
• Certification：RoHS, CE, ISO
• Transport Package：Export Standard Carton or Customize Strong Pallet
• Specification：CE
• Trademark：Grewin
• Origin：China
• HS Code：85043190
• Production Capacity：100PCS

Basic Info.

Model NO. ADSGW22-2 Max.Winding Speed 2200rpm Wire Spacing Proportional Linkage Supply Voltage AC 220V(50Hz) Mechanical Dimensions 720×950×1300mm Weight 180 Certification RoHS, CE, ISO Transport Package Export Standard Carton or Customize Strong Pallet Specification CE Trademark Grewin Origin China HS Code 85043190 Production Capacity 100PCS

Product Description

Product Description:

Automatic toroidal transformer winding machine adopt precision digital toroid controller, it's an accurately and reliability digital automatic toroid-taping machine. it is used for the insulation tape wrapping machine on the toroidal core and windings. it is best suited to toroidal inductor, toroidal transformer, toroidal current transformer, toroidal coil, toroid choke coil, power inductors, power magnetics, UPS inductor, converter inductors, heavy toroidal core,etc.

Specification
 ADSGW22-2 Ceiling fan winding machine

Specifications:

Spindle number	2
Wire size range	0.1-1.2mm
Loop diameter	200mm
The max wire spacing	9.99mm
Winder width	100mm
Max speed	2200 RPM
Spindle motor	Three Phase motor+AC Driver
Winder motor	Stepping motor
Input power	220V  50HZ/60HZ
Machine size	720×950×1300mm
Package size	860×1400×1320mm
Net weight	180kg
Gross weight	220kg

Features:
This Ceiling fan winding machine design of 32 bit controller chip, It'll be faster and higher reliability.
In Chinese and English display,easy to operation,winding data retention after power failure, not to discarded products.
All the parts for this machine are imported prats,such as:Japan Bearing (NSK,NTN),Japan BANDO belt ,U.S.A GATES belt ,Taiwan Ball screw (TBI),Taiwan AC Drive and so on.
Fan Winding Machine use two spindle synchronous design, selection of high-power phase motor, making a thick wire around the low-speed torque when larger and more stable. Coupled with high-power stepper motor ,when it rotates will get higher accuracy, so that customers to feel save time,save worker,high production.
Stator Winding Machine suitable for all kinds of  motor stator winding, a variety of ceiling fan stator, pole number stator, locomotives generators.

Advantages:
Ceiling fan winding machine design of 32 bit controller chip, It'll be faster and higher reliability.
In Chinese and English display,easy to operation,winding data retention after power failure, not to discarded products.
All the parts for this machine are imported prats,such as:Japan Bearing (NSK,NTN),Japan BANDO belt ,U.S.A GATES belt ,Taiwan Ball screw (TBI),Taiwan AC Drive and so on.
Warranty period 1 year
The technicians are experienced



 Related Products:
GW-9761 High Speed Parallel Winding Machine

SPECIFICATION:

Spindles	1	Spread Motor	4-Phase stepping Motor
Wire diameter	0.02-0.8mm	Max Speed	6000rpm
Spread Pitch	0-9.999mm	Memory	999 Sequences
Spread Width	100mm(Max)	Power Source	AC 220V/110V±10%,50/60MHZ
Winding Width	150mm(Max)	Weight	45×67×10
Main Motor	1/2HP DC Motor	Dimension	45

ACGW28-80 High Speed Winding Machine

Specifications:

Spindle number	8
Wire size range	0.03-0.2mm
Loop diameter	56mm
Max wire distance	9.99mm
Winder width	60mm
Spindle pitch	70mm
Max speed	0-10000RPM
Spindle motor	Three Phase Motor+AC Drive
Winder motor	Stepping motor
Input power	220V 50HZ/60HZ
Machine size	1080×800×1100mm
Package size	1180×890×1130mm
Net weight	167kg
Gross weight	204kg

GWCM-1901 Semi auto voice coil winder

Specifications

Spindle number	1
Wire size range	0.02-1.2mm
Winding width	0-110mm
The max coil diameter	150mm
Max speed	6000 RPM
Spindle motor	Brushless DC motor
Winder motor	Stepping motor
Machine power	220V  50HZ
Machine Size	750*400*450mm
Package size	1090×620×620mm
Net weight	72kg

ACGW23-1B Fishing line winding machine

Specifications

Spindle number	1
Wire size range	0.05-1.0mm
Loop diameter	140mm
Max wire distance	9.9mm
Winder width	600mm,1500mm
Max. speed	0-1500RPM
Spindle motor	Three Phase motor+AC Drivers
Winder motor	stepping motor
Max. winder diameter	80mm
Input power	220V  50HZ/60HZ
Machine size	1130×450×450mm
Package size	1000×830×1110mm
Net weight	95kg
Gross weight	151kg

ATWGW22-1 Speaker Voice coil winding machine

Specifications

Spindle number	1
Wire size range	0.3-2.0mm
Loop diameter	240mm
The max wire spacing	9.99mm
Winder width	180mm
Max speed	0-2200 RPM
Spindle motor	Three Phase motor+AC Drives
Winder motor	Stepping motor
Input power	220V  50HZ/60HZ
Machine Size	1000×520×430mm
Package size	1090×620×620mm
Net weight	98kg
Gross weight	143kg

How to select the best suited automatic toroid taping machine for your toroid coil?
Tell us your toroidal coil of data as below please:
1.toroid core outside diameter before winding?
2.toroid core inside diameter before winding?
3.toroid core height before winding?
4.how many windings on this core?
5.how many tape windings total on this toroidal coil?
6.how about the tape width of each tape winding?
7.how many turns of each tape winding?
8.provide pictures of product which is better.

Packaging Information:
Wooden case package: For larger scale goods as machine equipment etc, we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock. We will inform you the delivery note. You just need to wait for phone call, then pick up the goods at the nearest logistic station .(Please let me know in advance if you want get the goods at home.) Packaging: Packaging material: Carton/Wooden case with foam inside.
