• Model NO.：XJ-500MM
• Pay off Bobbin Size：500mm
• Tension Range：1-20n
• Pay off Speed：0-120m,Min
• Back Twist Rate：0-50%
• Back Twist Driving Motor：4kw
• Pay off Motor：0.75kw
• Load&Unload System Driving Motor：0.75kw
• Model：LAN Cables Pair Twisting Machine
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Automatic Grade：Automatic
• Customized：Customized
• Transport Package：PE Shrink or Wooden Box Package
• Specification：500mm
• Trademark：Newtopp
• Origin：China Mainland
• HS Code：8479400000
• Production Capacity：20 Set,Month

Basic Info.

Model NO. XJ-500MM Pay off Bobbin Size 500mm Tension Range 1-20n Pay off Speed 0-120m/Min Back Twist Rate 0-50% Back Twist Driving Motor 4kw Pay off Motor 0.75kw Load&Unload System Driving Motor 0.75kw Model LAN Cables Pair Twisting Machine Precision High Precision Demoulding Automatic Heating System Electric Automatic Grade Automatic Customized Customized Transport Package PE Shrink or Wooden Box Package Specification 500mm Trademark Newtopp Origin China Mainland HS Code 8479400000 Production Capacity 20 Set/Month

Product Description

Automatical Triple-Core Twist Stranding Machine for Cat5a, CAT6A, Cat7a Cable

  1.Usage: Suitable for cat5, cat5e, cat6,cat7 Lan Cable pair twisting.
  2.Machine Features:
   1) Triple pitchs design, 1.5 times speed to traditional double twisting machine when with 33% back twisting rate;
    2) Servo electonic pitch, setting by touch screen, PLC controller, accuracy within 2%;
    3) Active take-up, tension stable from empty to full bobbin.
 3.Technical Parameters:

Model	XJ-500
Usage	Suitable for cat5, cat5e, cat6,cat7 Lan Cable pair twisting.
Rotate speed	Max.1800rpm
Suitable wire diameter	0.8-1.7mm
Twisted OD	1.5-3.5mm
Twisting pitch	50-50mm; electric pitch setting by touch screen
Pitch tolerance	±2%
Back-twist rate	0-100%
Tisting direction	S/Z
Tension display	Digital tension display
Pay-off and Take-up tension	Stable active rail tension
Motor power	Twist-bow motor 10HP, 1/2HP gear motor driving, with frequency inverter.

4. Brand of main parts:
1) Motor: Siemens; TECO
2) Driver: Yaskawa or inovance
3) Bearing:NSK, NACHI, ASCHI
4) Electric components: Omron
Dear my friend,
       Good day to you!
       This is Delicia Xing from Dongguan NewTopp Electrical Machinery Co.,Ltd.
About coiling machine,it should be written on the top:
     Customized products are what we reccomend.We prepare three (Of course,even more) combination arrangement to meet different wire demands and diversified needs of our customer.Our coiling/winding machine can be applied for coiling/rewinding of all kinds of wire or cable such as Lan cable,Power cable,HDMI etc.
 Hope you can read through our company introduction below. However,if you are in urgent need of wire/cable equipment,I also prefer to receive your name card , pictures of original products and product that you want to achieve at first and get exact inquiry from you.Thank you so much! ∧ω∧
       Followings will let you have a general idea of us:
       Our company  running for over ten years in designing and manufacturing automatic wire&cable equipment locates in the  manufacturing center--Humen Town,DongGuan City,GuangDong Province,China.We have mature production technology  applying for whole set production line of HDMI,LAN cable,power wire,USB3.0/3.1,Car wire,data wire,high frequency wire,earphone wire etc.from extrusion,twisting,taping,cutting,coiling/rewinding to packing etc.
       Our strength:
1.Factories:
Two factories are in wire&cable equipment manufacturing center distributing in south and north China.
2. Expos:
Every year we regularly attended over 6 international wire&cable Expos home and overseas.(Russian(March),Germany(April),ShangHai(September),Thailand(September),India(November) etc.)
3.Output:
The annual output is around 600 sets. Our annual sales in 2019 has reached up to one hundred million.
4.HR:
NewTopp team has been up to 200 staffs until 2020,and the quantity is still rising.
5.Technology:
As brain of NewTopp,it provides continuous software system support and technological update . Every year we invite foreign professional engineers from our partners to attend annual technical seminar.
6.Overseas Market:
We have got a wide market in southeast Asia.We mainly sold our equipment to Russia, Iran, Italy, Turkey, South Korea, Japan,Vietnam, India, Saudi Arabia ,Indonesia  ect.
7.Partners:
Two of our long-term cooperative partners are:
Luxshare-ICT: ranks the 74th on the list of 2020 market capitalization top 500 in China)
BELDEN: Belden Inc.&Cable Design Technologies Corp) .

Best regards,
