• Model NO.：reflow oven F8
• Warranty：12 Months
• Automatic Grade：Automatic
• Installation：Vertical
• Type：Reflow Solder
• Place of Origin：Guangdong, China
• Brand Name：Reflow Oven
• Model Number：F8
• Usage：Welding
• Voltage：380V
• Weight：1900kg
• Rated Capacity：40kw
• PCB Size：30-420mm
• Reflow Oven Waring：1 Year
• No. of Heating Zone：up Eight Bottom Eight
• No. of Cooling Zone：up 2 Bottom 2
• Length of Heating Zone：3890mm
• Conveyor：Mesh+Rail
• Transport Package：Wooden Packing and Vacuum Packing and Wooden Pakin
• Specification：5300*1320*1550mm
• Trademark：Jaguar
• Origin：Shenzhen
• HS Code：8515190000
• Production Capacity：100PCS,Month
• Package size per unit product：550.00cm * 152.00cm * 169.00cm
• Gross weight per unit product：1800.000kg

Jaguar F8

Heating System

Number of heating zones

Up 8/ bottom 8

Number of cooling zones

2

Length of heating zones

3121mm

Heating mode

Hot air

Cooling Mode

Forced air cooling

Exhaust Volume

10m³/min * 2 exhausts

Conveyor System

Max. Width of PCB

420mm

Mesh belt width

500mm

Transmission Direction

L→R(option: R→L)

Transmission Net Height

900±20mm

Transmission type

Mesh and chain

Range of rail width

50-420mm

Conveyor speed

0-2000mm/min

Auto/manual Lubrication

Standard

Fixed rail side

Front rail fixed(option: rear rail fixed)

Components high

Top and bottom 25mm

Control system

Power supply

5 line 3 phase 380V 50/60HZ

Total power

48KW

Starting power

40KW

Normal power consumption

8KW

Warming time

20 mins

Temp. setting range

From room temp. To 300ºC

Temp. control method

PID close loop control & SSR driving

Temp. control precision

±1ºC

Temp. deviation on PCB

±2ºC

Data storage

Process Data and status storage(80GB)

Nozzle plate

Aluminum Alloy Plate

Abnormal Alarm

Abnormal temperature (extra-high/extra-low temperature)

Board dropped alarm

Tower light:

Yellow-warming, Green-normal, Red-abnormal

General

Dimension(L*W*H)

5300*1320*1490mm

Weight

1800kg

Color

Computer gray

Features:

1.It adopts imported thermostat control which owns fuzzy control and PID intelligent precision control system.It can fast response the changes in external heat and ensure more temperature balanced by PID intelligent operation and automatic control heating .

2. Using thermocouple imported from Taiwan by each temperature zone, it can fast and sensitive induct the changes in each temperature zone, transfer and control timely, compensate the temperature balance in each zone .

3 .Special SSR solid state relay matched with dedicated radiator improve the heat efficiency greatly and prolong the lifetime effectively. No contact output and fuzzy control function by thermostat, can monitoring the changes of outside temperature and calorific value, controlling the heating device by minimum pulse, ensuring the high precision of the temperature control & the uniform temperature in internal and the length ,direction, temperature distribution, all of these meet IPC standards .

4. Power is abundant, heat up fast, it's only need 20 minutes from room temperature to constant temperature.

5 .Failure diagnosis and sound light alarm.

6. Delay shutdown production function, uniform cooling after the shutdown: prevent component deformation.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
