• Model NO.：HH-FC06
• Color：Blue or Customization
• Power(V)：380V
• Certificate：ISO,CE
• After-Sales Service Provided：Engineers Available to Service Machinery Overseas
• Transport Package：Wood Package
• Specification：CE ISO SGS
• Trademark：GEM
• Origin：Dongguan
• HS Code：8479400000
• Production Capacity：5 Sets,Month

Basic Info.

Model NO. HH-FC06 Color Blue or Customization Power(V) 380V Certificate ISO/CE After-Sales Service Provided Engineers Available to Service Machinery Overseas Transport Package Wood Package Specification CE ISO SGS Trademark GEM Origin Dongguan HS Code 8479400000 Production Capacity 5 Sets/Month

Product Description

Video link on Youtube:
https://hoohaco.en.made-in-china.com


1,Equipment application :
 The optical fiber coloring and rewinding machine mainly applied for coloring the surface of optic fibers, convenient to identify the multi-fibers within the loose tube. Also can be used to rewind fibers and coat the nylon-tight fibers with the silicone gel .

2,features:
  a,Main  function :coloring the surface of optic fibers
  b,Auxiliary function: rewiding the optic  fiber
  c, the machine use PLC control system, main electric parts  are importing,
  d, high production efficiency, convenient operation.

3,Equipment application:

No of optical fiber	1 piece
Coloring speed	1000-1200m/min
Structure speed	1500m/min
Rewinding speed	<=1500n/min
Coloring layer thickness	3-5um
Pay-off tension	0.4N-1.2N±0.05N
Traversing pitch	0.2-1.5mm
Excess loss after coloring	<=0.02db/km
Optical fiber reel size(MAX)	ø350×ø25.4×ø300mm,weight:5kg(25km/50km reel)


4,Main parts brand:

Motor: Siemens motor

Transducer: American Emerson transducer

PLC: Siemens S7 series

Temperature controller: FOTEK temperature controller PID smart type

Screw and barrel: Designed by Taiwan LIQI company
Bearing: Japan NSK

Electrical parts: adopt OMRON, FOTEK, SHILIN brands, etc.
