• Model NO.：XJ-70,80,90MM
• Extrusion Material：PVC,PE
• Power：50HP
• Highest Output：180kg,H
• Highest Wire Speed：300m,Min
• Capstan Power：7.5HP
• Pay off Type：as Requirement
• Temperature Control：5+3 Segments (Body+ Head)
• Usage：Power Wire,Computer Wire etc Insulation Extrusion
• Precision：High Precision
• Demoulding：Automatic
• Heating System：Electric
• Function：High Temperature Resistance
• Automatic Grade：Automatic
• Customized：Customized
• Transport Package：Wooden Box,Pallet
• Specification：cable machine
• Trademark：Newtopp
• Origin：Chinese Mainland
• HS Code：8479400000
• Production Capacity：60 Sets,Month

Equipment modelXJ-70XJ-80XJ-90XJ-120Usage:Power Wire/ computer wire/ building wire/data wire/ high frequency wire insulation/jacket sheath extrusionWire specification1.5-12mm2-20mm3-25mm10-50mmExtrusion materialPVC/SRPVC/LHNF/PE/PP/PU etcScrew parameterL/D ratio:26:1, compression ratio: 2.7-3.2, Screw material:38CrMoAIA, Vacuum heating treatment, Surface Grinding Polishing chromium platingTemperature control segments (body+head)5+35+36+36+3Power40HP50HP60HP100HPThe highest output140KG/H180KG/H240KG/H360KG/HThe highest wire speed400M/min300M/min250M/min180m/minMovable water tankExtension type movable tank, movable lenth is 300mm, over length 1.5m with single segment water dryer. Or as requirementLength of U type cooling tank7.5M7.5M10M15MAccumulate wheel parameter(11+10 grooves)250300400500Capstan power5HP7.5HP7.5HP15HPpay off typeHow may shafts, active with moter and passive without moter just as requestTake up TypeAs request
 120-150mm jacket sheath extruder (bigger machine can be made also)

Equipemnt model	XJ120	XJ150
Pay off type	big shaft	big shaft
Bobbin size	1600-2000	2500-3150
Screw diameter	120	150
L/D of screw	26:1	26:1
Extrusion capacity	360kg/h	600kg/h
Power	100HP	150HP
Wire specification	10-50mm	60-120mm
cooling tank	single layer u type	Single layer U-type
Capstan power	15HP	20HP
Highest wire speed	180m/min	100m/min
Take up type	Big shaft	Big shaft






More cable production line such as data/high frequecy cable USB3.0/3.1, HDMI, DVI, SATA etc, please kindly contact the below information:
Dongguan NewTopp Electrical Machinery Co..,Ltd.


Website:  http://dgnewtopp.en.made-in-china.com/    http://dgnewtopp.en.made-in-china.com
Add: No.286 Huaide Road, Humen town, Dongguan City, Guangdong province,China
We are looking forward to hearing from you, dear friend!
