• Model NO.：SR-400
• Power：220V,50Hz5w
• Weight：30kg
• Dimension：430*390*300mm
• Cutting Range：0.01mm²~72mm²
• Atmospheric Pressure：80kpa~106kpa
• Power Consumption：180W
• Transport Package：Carton
• Specification：430*390*300mm
• Trademark：sinrad
• Origin：China
• HS Code：8479899990
• Production Capacity：100 Sets,Month

Parameters Name    Parameters DatasMotor/speed2800 revolutions/min (adjustable) German brushless motorCutting range diameter 0.01mm---8mmCutting speed1.6mm/secCutting wheel inner diameterinner diameter 32mmCutting wheel Outer diameter 150mmThickness 0.5mmGrinding speed 1400 rpm (adjustable)Grinding disc diameter 150mmGrinding disc thickness 6mmDedicated terminal clamp 1PCSPower switch 220V/50HZCorrosion part Corrosion time 5-30minImaging system 1/3″ professional CCD high-definition imaging system(3 million pixels (CCD gigabit network,The card access screen is clear and transmission speed Fast and stable))Terminal dedicated analysis measurement
Software 1PCSMagnification: 16X~260X continuous zoomMeasurement accuracy 0.004mmOptical lens 0.7~4.5X (Hong Kong joint venture) Pumisco End stopHigh precision standard block calibration sheetTerminal measuring range 0.01mm2-50mm2Lighting sourceAll white adjustable LED lighting device (cold light)Warranty period 1 yearCompany Information

Sinrad Technology Co., Ltd is an international high Tech company specializing in R&D, production and sales automation machine. We mainly engaged in R&D and sales on intelligent production lines and non-standard automation equipment which we can provide professional solution for your production line.

We mostly focus on wire harness processing machine, (cutting, striping, twisting, crimping, housing inserting, soldering, testing machine), intelligent soldering robot, welding machine and so on. Sinrad Tech has developed 3 factory for automation soldering machine, cable automotive machine and laser welding machine. We have committed to creating the first brand of automation robot in China.

In the future, Sinrad Technology will deeply in develop more multi-automatic machine & automation robot for striving as outstanding enterprises in the automation field.

Certificate
