• Model NO.：FC-300B,400B,500B,650B,800B,1000B,1250B
• Type：High-speed Stranding Machine
• Twisting Usage：Bare Copper Wire,Tinned Wire,Silver Jacketd Wire,
• Single Wire Diameter：0.15mm-1.04mm
• Stranding Section Area：0.35-6.0mm2
• Core Wire Single Wire Dia：1.0mm-6.0mm
• Pitch：11.6-100mm(34zones)
• Direction of Lay：Optional for Right or Left
• Take up Bobbin Size：630*56*475,630*127*475
• Max Rotating Speed：2000rpm(4000twist)
• Main Motor Power：7.5kw
• Tension Control Method：Touch Screen+PLC+Magnetic Powder Clutch
• Transport Package：Simply Packed
• Specification：ISO
• Trademark：FC
• Origin：China
• HS Code：8479811000
• Production Capacity：50PCS,Month

The technology of this machine is brought from Japan and put in production in Jiangsu.Series for Model-B normal wire high speed bunching machine & double twisting machineMerits: With high rotation speed, with constant tension from empty bobbin to full bobbin, with  superior quality for twist wire.The machine is driven by synchronization strap. Only need to change capstan wheel to change the pitch. Easy to operate.     Equipment ModelFC-500BFC-650BFC-650CFC-800BUsageIt is applied to the twisting of above 7pcs of bare copper wires,tinned wires,silver jacketed wires and enameled wires and double twisting for core wires.Single Wire Dia(mm)Φ0.08~0.45Φ0.15~1.04Φ0.12~0.52Φ0.38~1.7 Stranding Section Area(mm²) 0.05~2.50.35~6.00.30~4.01.0~16Core Wire Single Wire Dia(mm)Φ0.5~1.5Φ0.5~3.0Φ0.5~2.0Φ1.0~4.0Core Wire Stranding Outer Dia(mm)Φ1.0~3.0Φ1.0~6.0Φ1.0~4.0Φ2.0~8.0Pitch(mm)6.3-52.3(24pcs pitch)11.6-100(34pcs pitch)11.6-100(34pcs pitch)23-147(20pcs pitch)Direction of Layoptional for right or left Take-up Bobbin(mm)     Φ500*Φ56*375/Φ500*Φ127*375     Φ630*Φ56*475/Φ630*Φ127*475     Φ630*Φ56*475/Φ630*Φ127*475     Φ800*φ80*600Max Rotating Speed(rpm)3000(6000twist)2000(4000twist)2400(4800twist)1500(3000twist)Main Motor Power 5.5KW7.5KW11KW15KWInverter Power5.5KW7.5KW11KW15KWTension Control MethodTouch screen+PLC+magnetic powder clutch,it may ensure the constant tension from empty bobbin to full bobbin.Magnetic Powder Clutch1.2kgf5kgf2.5kgf10kgfProtection Machine will automatically brake when wire inside and outside is broken,the machine will automatically stop when the preset length is arrived.Brake ModeElectromagnetic BrakeTraversing MethodRolling ring drive units, winding pitch and breadth are adjustable.Operation ModeTouch Screen Operation Dimension(mm)2680L*1250W*1500H3300L*1550W*1800H3300L*1550W*1800H4600L*2000W*2000H
