• Model NO.：reflow oven machine A6
• Heating Mode：up:Hot Air; Bottom: IR
• Max. Width of PCB：350mm
• Mesh Belt Width：400mm
• Transmission Net Height：880±20mm
• Transmission Type：Mesh
• Conveyor Speed：0-1000mm,Min
• Total Power：28kw
• Warming Time：About 20 Mins
• Abnormal Alarm：Abnormal Temp
• Transport Package：Wooden Case
• Specification：3500*700*1320mm
• Trademark：jaguar automation
• Origin：Shenzhen
• HS Code：8515190000
• Production Capacity：100pieces,Year

JAGUAR A6





Heating System

Number of heating zones

UP 6/BOTTOM6

Length of heating zones

2400MM

Heating mode

Up:hot air; bottom: IR

Cooling Mode

Force air







Conveyor System

Max. Width of PCB

350mm

Mesh belt width

400mm

Transmission Direction

L→R(or R→L)

Transmission Net Height

880±20mm

Transmission type

Mesh

Conveyor speed

0-1000mm/min

Fixed rail side

Front rail fixed(option:rear rail fixed)

















Control system

Power supply

5 line 3 phase 380V 50/60Hz

Total power

28kw

Starting power

24kw

Normal power consumption

4KW

Warming time

About 20 mins

Temp. setting range

Room temperature-300ºC

Temp. control method

PID close loop control & SSR driving

Temp. control precision

±1ºC

Temp. deviation on PCB

±2ºC

Data storage

Process Data and status storage

(80 GB)(machine with PC)

Nozzle plate

Aluminum Alloy Plate

Abnormal Alarm

Abnormal temp. (extra-high/extra-low temp.)

Board dropped alarm

Tower light:yellow-warming, Green-normal,  Red-abnormal



General

Dimension(L*W*H)

3500×700×1320mm

Weight

600KG

Color

Computer gray
