Jaguar Hot Air Reflow Oven Machine with 10 Heating Zones and Ce Certificate

Shenzhen Jaguar Automation Equipment Co., Ltd.
  • Condition：New
  • Certification：CCC, RoHS, ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Installation：Vertical
  • Length of Heating Zones：3700mm

Base Info

  • Model NO.：F10
  • Heating Mode：Hot Air
  • Cooling Mode：Forced Air Cooling
  • Exhaust Volume：10m³,Min * 2 Exhausts
  • Max. Width of PCB：400mm
  • Mesh Belt Width：450mm
  • Transmission Type：Mesh and Chain
  • Conveyor Speed：0-2000mm,Min
  • Components High：Top and Bottom 25mm
  • Total Power：58kw
  • Transport Package：Wooden Case
  • Specification：5400*1320*1490mm
  • Trademark：JAGUAR AUTOMATION
  • Origin：Shenzhen
  • HS Code：8515190000
  • Production Capacity：100pieces,Month

Description

JAGUAR F10

Heating SystemNumber of Heating ZonesTop 10/ Bottom 10 Number of Cooling Zones2(Top 2, Bottom 2) Heating Passage3890mm Heating StyleHot Air Cooling StyleForced Air Cooling Exhaust Volume10m³/min * 2 Exhaust




Conveyor SystemMax. Width of PCB420mm Mesh Belt Width500mm Conveyor DirectionL→R(option: R→L) Process Height900±20mm Conveyor TypeMesh and Chain Conveyor Speed0-2000mm/min Auto LubricationStandard Fixed TrackFront Track Fixed(Option: Rear Track Fixed) PCB ClearanceTop and Bottom 25mm







Control SystemPower Supply5 line 3 phase 380V 50/60HZ Total Power58KW Startup Power50KW Steady Consumption10KW Ramp Up Time20 mins Temp. Setting RangeFrom Room Temp. to 300ºC Temp. Control MethodPID Close Loop Control & SSR Driving Temp. Control Precision±1ºC Data StorageProcess Data and Status Storage(80GB) Nozzle PlateAluminum Alloy Plate Abnormal AlarmAbnormal Temperature (Overtemp/Low Temperature) Board Dropped AlarmTower Light:
Amber-warming, Green-normal, Red-abnormal
GeneralDimension(L*W*H)5800*1320*1490mm Weight2300kg ColorComputer Grey
