• Model NO.：R350
• Temperature Control Segment：40 Segment .The Segment Can Be Set in Computer Acc
• Temperature-Zone Numbers：Single-Zone and Multi-Segment
• Temperature Control System：PC Control System ,SSR Non-Contact Output.
• Warm-up Time：3min
• Heating Supply：Infrared Ray + Hot Air Convection
• Effective Working Table Area：360mm * 230mm (Less Than A4)
• Welding Time：3min±1min
• Temperature Curve：It Can Be Set ,Adjusted and Tested According to Th
• Cooling System：Transverse Flow Equal Cooling
• Weight：39kg
• Transport Package：Wooden Case
• Specification：CE
• Trademark：Torch
• Origin：Beijing
• HS Code：8514109000

Item
Parameter
Temperature-zone numbersup and down total12groups temperature zone + 4 groups inline testing
Temperature control system
PC control system ,SSR non-contact output.
Temperature accuracy
±2ºC
Warm-up time
3min
Temperature range
Room-temperature -360 ºC
Heating supplydark infrared ray + hot air convection
Effective working table area600mm *350mm
Welding time
3min±1min
Temperature curvecan be set by requirements,meanwhile real time test and analyst welded circuit board temperature
Cooling systemwind cooling,can use air cooler to reduce temperature rapidly
Rated voltage
AC single-phase ,220V;50Hz
Rated power
7.8KW
Mean power
2.5kw
Weight
150kg
Dimension
Length*width*height 1500*700*520mm
