Gear Motor Stator Semi-Automatic Coil Winding Insertion Machinery

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：380V
  • Max Stator O.D.：0~160mm
  • Stator I.D：20~110mm
  • Slot Number Range：8~48 Slots
  • Appropriate Wire：Copper,Alum Wire
  • Power Source：380V,50Hz

Base Info

  • Model NO.：QB1-150,160
  • Machine Dimension：1500*680*1500mm
  • Weight：About 400kg
  • After-Sales Service：Overseas Service Center Available
  • Conditon：New
  • Working Station：One
  • Automatic：Semi-Automatic
  • Certification：CE
  • Transport Package：Wooden Case Suitable for Sea Transportation
  • Specification：ISO9001
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479819000
  • Production Capacity：250set,Year

Description

Stator I.D20~110mmStator O.D0~160mmStator stack length20~150mmTooling travel60mmAppropriate wireCopper/Alum wireSlot number range8~48slotsPower source380V/50/60Hz 3KwDimension1500*680*1500mmWeight≈ 400kg
Machine fetures:
This machine is used to inserting coil and wedge into stator. And it can insert coil and wedge simultaneously. This HMI can set all the necessary data. With easy and convenient tooling change process, this machine is suitable for three phase motor, fan motor and other motor, with a veriety model number but low output.


Information needed for stator winding inserting machine inquiry
It will be better if customer could send us detailed drawing including below information.
1. Stator lamination drawing
2. Stator stack drawing
3. Wire connection drawing
4. Stator application
5 Required productivity
6 Other technical requirement
