Air Conditioner Motor Stator Semi-Automatic Coil Winding Inserting Machine

Ningbo Nide Mechanical Equipment Co., Ltd.
  • Voltage：380V
  • Max Stator O.D.：0~160mm
  • Stator I.D：20~110mm
  • Slot Number Range：8~48 Slots
  • Appropriate Wire：Copper,Alum Wire
  • Power Source：380V,50Hz

Base Info

  • Model NO.：QB1-150,160
  • Machine Dimension：1500*680*1500mm
  • Weight：About 400kg
  • After-Sales Service：Overseas Service Center Available
  • Conditon：New
  • Working Station：One
  • Automatic：Semi-Automatic
  • Certification：CE
  • Transport Package：Wooden Case Suitable for Sea Transportation
  • Specification：ISO9001
  • Trademark：NIDE
  • Origin：China
  • HS Code：8479819000
  • Production Capacity：250set,Year

Description

Stator I.D20~110mmStator O.D0~160mmStator stack length20~150mmTooling travel60mmAppropriate wireCopper/Alum wireSlot number range8~48slotsPower source380V/50/60Hz 3KwDimension1500*680*1500mmWeight≈ 400kg
Information needed for stator winding inserting machine inquiry
It will be better if customer could send us detailed drawing including below information.
1. Stator lamination drawing
2. Stator stack drawing
3. Wire connection drawing
4. Stator application
5 Required productivity
6 Other technical requirement

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Air Conditioner Motor Stator Semi-Automatic Coil Winding Inserting Machine
Air Conditioner Motor Stator Semi-Automatic Coil Winding Inserting Machine
Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
