Electrical Wire, Power Wire Extrusion Cable Winding Extruder Bunching Buncher Coiling Double Twisting Machine
Kunshan Fuchuan Electrical and Mechanical Co., Ltd.- Driven Type：Electric
- Condition：New
- Certification：ISO, CE
- Warranty：12 Months
- Screw：Single-Screw
- Usage：PVC,PP,PE,Sr-PVC and Other Plastic Material
Base Info
- Model NO.：FC-70+35
- Mechanical Model：FC-50+35,FC-60+35,FC-70+35
- Pay off Type：500-630active Pay off or Lut Barrel
- Screw Diameter：50
- Screw Ratio：25:1
- Extrusion Output：60
- Main Power：15kw
- Cooling Device：Double Layer Model U
- Capstan Power：3.7kw
- Max Accumulating Length：200m
- Transport Package：Simply Packed
- Specification：ISO
- Trademark：FC
- Origin：China
- HS Code：8477209000
- Production Capacity：50PCS,Month
Description
Basic Info.
Model NO. FC-70+35 Mechanical Model FC-50+35/FC-60+35/FC-70+35 Pay off Type 500-630active Pay off or Lut Barrel Screw Diameter 50 Screw Ratio 25:1 Extrusion Output 60 Main Power 15kw Cooling Device Double Layer Model U Capstan Power 3.7kw Max Accumulating Length 200m Transport Package Simply Packed Specification ISO Trademark FC Origin China HS Code 8477209000 Production Capacity 50PCS/MonthProduct Description
Product Parameter:
Mechnical model: FC-70+35
Pay-off type: Active type+Oscillating bar
Pay-off bobbin: 400/500/630mm
Screw dia: 70mm
Screw ratio: 26: 1
Revolving speed of screw: MAX: 500R. P. M
Extrusion output: 140KG/H
Power for main machine: 11KW
Dia spec: 0.6-6.0mm
Cooling device: Double layer model U
Max accumulating length: 200m
Capstan power: 3.7KW
Outer wire speed: 0-800m/min
Take-up type: 1246 Automatic coiling machine
For more details of FC-70+35 Extruder Machine, please contact me.
