• Model NO.：FC-300B,400B,500B,650B,800B,1000B
• Single Wire Diameter：0.016mm-0.08mm
• Stranding Section Area：0.0014mm2-0.035mm2
• Pitch：0.8-4.0(14phase)
• Direction of Lay：Optional for Right or Left
• Take up Bobbin Size：Dia200*31*135
• Max Rotating Speed：5000rpm
• Main Motor Power：2.2kw
• Inverter Power：2.2kw
• Transport Package：Simply Packed
• Specification：ISO9001
• Trademark：FC
• Origin：China
• HS Code：8479811000
• Production Capacity：60sets,Month

Basic Info.

Model NO. FC-300B/400B/500B/650B/800B/1000B Single Wire Diameter 0.016mm-0.08mm Stranding Section Area 0.0014mm2-0.035mm2 Pitch 0.8-4.0(14phase) Direction of Lay Optional for Right or Left Take up Bobbin Size Dia200*31*135 Max Rotating Speed 5000rpm Main Motor Power 2.2kw Inverter Power 2.2kw Transport Package Simply Packed Specification ISO9001 Trademark FC Origin China HS Code 8479811000 Production Capacity 60sets/Month

Product Description

Japanese technology,product in China
Characteristics:Newly developed,with high rotating speed,with constant tension from empty to full bobbin,
with high quality products.This machine with pressure sensor,can check the tension on line,revert back
and rectify the tension figure;can also add the web control system,can sums several sets of machines
working information to one computer or mobile,then check the working condition of machines at any time,
such as :rotating speed,twisting specification,output and so on. to realize the far distance check and maintenance,so reach the fine management,lower the production and maintenance fees.

Equipment model:FC-650B
Twisting usage: Apply for automobile wire,electrical wire,power wire and so on(above seven pcs of bare copper wire,tinned wire,silver jacketed wires and enamelled wires)

Single wire diameter: dia0.16-1.04mm
Stranding section area: 0.40-6 sq mm
Pitch: 11.6-100
Take up bobbin size: dia630*56*475mm
Max rotating speed: 2000RPM(4000TPM)
Main motor power:7.5kw
Tension control method: touchscreen+PLC+magnetic powder clutch,ensure the constant tension from empty to full bobbin.
