Slotted Type Armature Coil Winding Machine

We produce both straight and skewed slot armature winding machine. Besides, we also provide coil winding machine, stator winding machine, needle winding machine, hairpin winding machine.

(1)Specification

Wire range	0.2~1.2mm
Armature OD	20~90mm
Stack height	10~130mm
Commutator OD	8~60mm
Movement	Jog/auto
Slot No.	Odd/Even
Turn No.	0~9999
Flyer speed	0~2000rpm
Power supply	AC 220V  50/60HZ
Air source	5~7kg/cm3
Power	3.5KW
Weight	830KG
Dimension	1530x1280x1650mm

(2)Feature
For riser type commutator
With medium and big wire diameter
Manual loading and unloading
Can work as a stand-alone machine or integrated into a production line
All winding parameter programmed on touch screen

(3)Application
This machine is suitable for slotted type armature with riser type commutator.

(4)Machine Operation
1)Put the armature on the tooling
2)Then press the start button.
3)Machine will wind the armature automatically
4)Unload wound armature
