• Model NO.：WIND-2B-TD
• Automatic：Automatic
• Transport Package：Wooden Case
• Specification：Middle Size
• Trademark：Wind Automation
• Origin：China
• HS Code：8479811000
• Production Capacity：100 Sets,Year

Basic Info.

Model NO. WIND-2B-TD Automatic Automatic Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/Year

Product Description

Rotor Winding Machine Armature Coil Winder For Riser-type Commutator

This machine can wind wire into coils. It is suitable for armature both straight and skewed slot with riser-type commutator.

(1)Specification

Wire range	0.2~1.2mm
Armature OD	20~90mm
Stack height	10~130mm
Commutator OD	8~60mm
Movement	Jog/auto
Slot No.	Odd/Even
Turn No.	0~9999
Flyer speed	0~2000rpm
Power supply	AC 220V  50/60HZ
Air source	5~7kg/cm3
Power	3.5KW
Weight	830KG
Dimension	1530x1280x1650mm

(2)Feature
For riser type commutator
With medium and big wire diameter
Manual loading and unloading
Can work as a stand-alone machine or integrated into a production line
All winding parameter programmed on touch screen

(3)Application
This machine is suitable for slotted type armature with riser type commutator.

(4)Machine Operation
1)Put the armature on the tooling
2)Then press the start button.
3)Machine will wind the armature automatically
4)Unload wound armature
