• Model NO.：ND-KZ160
• After-Sales Service：Overseas Service Center Available
• Machine Color：Ral9010 or as Per Customer Requirement
• Automatic：Automatic
• Certification：CE
• Transport Package：1 Ply-Wooden Case
• Specification：ISO
• Trademark：NIDE
• Origin：China
• HS Code：8479899990
• Production Capacity：100 Sets,Year

Stator ID
30~100mm
Max. Stator OD
160mm
Stator stack length
15~100mm
Displacement of oil pump
20F
Power Supply
380V/50/60Hz
Machine productivity
About 1500pcs/8hours
Machine weight
800kg
Machine Dimension
1200*700*2200mm

Description:
Stator Winding Pre-forming Machine is driven by hydraulic system; PLC programming; tooling expansion slice makes the first coli and inter-phase insulation paper in slot adjacent, leaving enough space for second insertion and ensurethe quality of successive coil insertion; apply to multi-layer stator winding insertion.

Applications:
After inserting the first winding, use this machine to form the winding into specified dimension, so that the next winding inserting could be easier and convenient. It is used for stator which meet the specification of below.


Competitive advantages
Variety of application, easy operation.
We directly supply our machine to many countries, like USA, France, Turkey, Iran, India, Brazil, Argentina, Mexico etc.
We could customize machine for our customer.

Information needed for formng machine inquiry
It will be better if customer could send us detailed drawing including below information.
1. Stator lamination drawing
2. Stator stack drawing
3. Stato winding drawing
4. Required productivity
5. Other technical requirement
If possible, it will be better if customer can send us samples.

With good service, unique philosophy, professional team and reliable quality, we win the worldwide customers' confidence gradually. We directly and indirectly supply our products to more than 50 countries .

Customerized service1. Customized product design and manufacturing2. Customized tranning3.Technical suggestionsAfter-sales service1. Warranty Period: 12 month usually2. Overseas service center available

3. Engineers available to service overseas

Established in 2007, NIDE is a company devoted in the field of electric motors manufacturing, providing one-stop service for its customers.

NIDE has three main business divisions.
The first division is to provide different kinds of motor manufacturing machines, it is our Main business, including stand along machine, fully-auto complete line for armature and stator production, and the motor assembly line.
The second division is to supply the full range of motor components such as commutator, ball bearing, carbon brush, insulation paper, shaft, magnet, fan, motor cover, etc.
The third division is to provide technical support and consulting, project support and turn-key service for some motor manufacturing.
