Segment Winding Machine Tooth Coil Winding Machine
Shanghai Wind Automation Equipment Co., Ltd.- Voltage:220V
- Warranty:12 Months
- Working Station:1
- Color:Customized
- Weight:450kg
- Dimension:1600X1100X1400mm
Base Info
- Model NO.:WIND-2-TSM
- After-Sales Service:Engineers Avaiable to Service Overseas
- Automatic:Automatic
- Transport Package:Wooden Case
- Specification:Middle Size
- Trademark:Wind Automation
- Origin:China
- HS Code:8479811000
- Production Capacity:100 Sets,Year
Description
Basic Info.
Model NO. WIND-2-TSM After-Sales Service Engineers Avaiable to Service Overseas Automatic Automatic Transport Package Wooden Case Specification Middle Size Trademark Wind Automation Origin China HS Code 8479811000 Production Capacity 100 Sets/YearProduct Description
Segment Winding Machine Tooth Coil Winding MachineThis tooth coil winding machine adopts a rectangle shape winding track, greatly improving machine productivity and winding quality. Wind Automation also provides customer with customized service, if stator beyond the specification listed blow.
(1)Specification
Wire diameter | 0.08~1.0mm |
Stator ID | Min 19mm |
Stack length | 7~90mm |
Turn No. | 0~9999 |
Movement | Stepping/Auto |
Slot number | 6,8,9,10,12,14,18(customized) |
Air source | 5~7kg/cm3 |
Power | 2KW |
Power supply | AC 220 V, 50/60HZ |
Weight | 450KG |
Dimension | 1600x1100x1400mm |
(2)Application
Suitable for various types of multi-poles stators, stepping motor, BLDC motor regardless of wire diameter.
(3)Features
Rectangle winding track
Fully programmable operation
Can meet high winding requirements
Precision performance of needle winding
Quick change-over of tooling
Suitable for stators with narrow slot width but high slot filling rate
(4)Machine configuration
Mitsubishi PLC
Touch screen
AIRTAC cylinder
Delta AC servo system and dual spindle synchronous control unit
Lubrication system
