• Model NO.：M6
• Max Mounting Area：350mm*200mm 350mm*350mm(Option) 600mm*350mm(Opti
• Z-Axis Maximum Movement Range：20mm
• Maximum Speed (Full Visual)：6000-7500cph
• Maximum Speed Patch (Non-Visual)：9000-11000cph
• Alignment Manner：Visual Position
• You Can Mount Components：0603-Sop24, Above Resistance-Capacitance
• Number of Feeders：1.Max60 Kinds of CF Feeders 2.Max30 Kinds of CF F
• Heating System：Electric
• Function：High Temperature Resistance
• Customized：Customized
• Transport Package：Wooden Case
• Trademark：torch
• Origin：Beijing

1

A number of heads

6

2

Max mounting area

350mm*200mm

350mm*350mm(option)

600mm*350mm(option)

3

Z-axis maximum movement range

20mm

4

Maximum speed (full visual)

6000-7500CPH

5

Maximum speed patch (non-visual)

9000-11000CPH

6

XY axis resolution Accuracy

±0.01mm

7

Repeat placement accuracy

±0.05mm

8

Alignment manner

Visual position

9

You can mount components

0603-SOP24,above resistance-capacitance and various pieces of LED chip,while meeting the diode Transistor SOP SOT PLCC QFP, BGA and other chips mount

10

Programming method

Universal Automatic data /Import image study / keyboard input

11

Kinds of component size

Can put 60kinds of CF feeders

12

Number of feeders

1.MAX60 kinds of CF feeders

2.MAX30 kinds of CF feeders

3.MAX18 kinds GFTA-08 feedesr

13

operating system

WINDOWS XP,WIN7

14

Compressed air

80psi(0.5Mpa,Gas flow≥120L/Min

15

power

220V,50Hz,1.5KW

16

weight

500kg

17

Overall size

1350(L)*930(W)*1300(H)

Best suitable products:

Power strip . with the power to absorb dome light. Led bulb.remote control board,and other small household appliances
