• Model NO.：SUNY-TPJ20
• Type：High-speed Chip Mounter
• Transport Package：Standard Export Package
• Trademark：SUNY
• Origin：Hunan China
• Production Capacity：500PCS,Month

Basic Info.

Model NO. SUNY-TPJ20 Type High-speed Chip Mounter Transport Package Standard Export Package Trademark SUNY Origin Hunan China Production Capacity 500PCS/Month

Product Description

Item: Hot Sale 2 Heads PCB Placement Machine LED Light Production Machine
Model: SUNY-TPJ20

Product Feature:
SUNY-TPJ20 is the classic of desktop dual-head SMT pick and placement machine. High precision, more reasonable mechanical design, easy operation, stable running, adapting air-operated feeder, automatic vision system, automatic detection materials shortage. Suitable for mounting most of the SMD components, such as 0402 0603 0805 1206 1210 3528 5050 SOP QFN, etc.
l Drawer type computer and driver integrated, could pull out lightly, convenient for later maintenance.
l Disassembled chassis, easy to handling.
l HD industrial camera, precisely identify 0402, 15*15mm and other electronic chips.
l Intelligent remounting design, when pick materials failed, software will instruct to continue mounting no-stop, record and unify remounting. It could improve the mounting efficiency.
l Component auxiliary box design, make components programming and position revising more precisely.
l Software is easy to understand and use, free upgrade permanently.

Product Parameters:

Model	SUNY-TPJ20
Max. Circuit Board Area	295x420mm
XY Max. Movement Range	530x550mm
Z Axis Max. Movement Range	20mm
Max. Mounting Speed	6000 CPH
Avarage Mounting Speed	5000 CPH
Positioning Accuracy	0.01mm
Nozzle Buffering Range	8mm
Power Supply	AC220V, 50Hz
Compressed Air	0.5~0.7Mpa
Avarage Power	300W
Support Feeding Method	Tape feeder, tube feeding, tray IC
Applicable Components	0402, 0603, 0805, 1206, 3528/ 5050/ 3014, diodes, transistors, QFN/ SOP/ SOT/ BGA/ Chip 100 pin or 15mm*15mm
Feeder No.	25
Moter	Stepper Moter
Mounting Head	2 Heads
Motion Driving System	High speed digital high pressure driver
Component Angle	0~360°, synchronized rotation in motion
Programming Mode	Point-to-point programming, visual programming, PCB file coordinates inputting etc.
Vision Operating System	Built-in PC, automatically recognize, correct and remount
X/Y Running Mode	A new generation of linear interpolation linkage
Air Source	Reversal positive and negative pressure switch
Visual Programming Camera	Ultra high pixel color infrared
Visual Display	15" Color HD display
Weight	168KGS
Dimensions	1045mm*850mm*650mm
