500mm High Precision Back-Twist+ Pair Twisting Machine

Dongguan Newtopp Electrical Machinery Co., Ltd.
  • Driven Type：Electric
  • Condition：New
  • Certification：CCC, PSE, UL, FDA, RoHS, ISO, CE
  • Warranty：12 Months
  • Automatic Grade：Automatic
  • Mould Life：300,000-1,000,000 Shots

Base Info

  • Model NO.：500mm
  • Type：To Back Stranding Machine
  • Precision：High Precision
  • Range of Application：0.4-1.5mm
  • Pay off Motor：0.75kw
  • Customized：Customized
  • Pay off Speed：0-120m,Min
  • Tension Range：1-20n
  • Back Twist Rate：0-50%
  • Back Twist Driving Motor：4kw
  • Max Rotate Speed：1000rmp
  • Transport Package：PE Film + Wooden Box
  • Specification：CE SGS
  • Trademark：NEWTOPP
  • Origin：Dongguan City, China
  • HS Code：8479400000
  • Production Capacity：100sets,Year

Description

Basic Info.

Model NO. 500mm Type To Back Stranding Machine Precision High Precision Range of Application 0.4-1.5mm Pay off Motor 0.75kw Customized Customized Pay off Speed 0-120m/Min Tension Range 1-20n Back Twist Rate 0-50% Back Twist Driving Motor 4kw Max Rotate Speed 1000rmp Transport Package PE Film + Wooden Box Specification CE SGS Trademark NEWTOPP Origin Dongguan City, China HS Code 8479400000 Production Capacity 100sets/Year

Product Description

LAN Cable Wire Twisting / Bunching Machine

Usage: Use for cat-5, cat-5E, cat-6 and so on lan (data) cable back-twist and pair twisting.

Feature: Back-twist before pair twisting and reduce the wire damage during twisting progress. Back-twsit and pair twisting machine worked together

Main part: XJ500 active back-tiwst pay off machine and 500 pair twsiting machine.

ModelXJ-500 Active Back-twist
Pay-off Machine
Max rotate speed 1000 RPM
Wire diameterΦ0.4-1.5MM
Pay-off bobbinΦ500MM
Tension range1-20N
Pay-off speed0-120M/MIN
Backtwist rate0-50%
Driving motor4KW
Pay-off motor0.75KW
Lifting motor0.75KW
Model XJ-500 Pair Twisting Machine
Wire diameterMaxΦ3.1mm
Pitch range 6-54.7mm
Rotate speedMax 2500RPM
Line speedMax 120M/min
Pay-off tensionTension ontrolled by slider rod feedback
Take-up tensionMagnetic powder clutch, bobbin size auto-tracking.
Take-up liftingAuto-lifting hydraulic pressure
Bobbin sizeΦ500mm
FQA:

Q: Are you the factory or trade company?

A: We are factory which etablish in year 2008 and 8000 square meter area.

Q: what certificate do you have?

A: we have the ISO9001 and ISO14001, the SGS, CE and many patents certificate.

Q: what is your company strong point?

A: Before year 2008, our business line is  Automatic control products, base on our former background, our cable machines will be more intelligence.
