• Model NO.：SM471
• Type：Ultra High-speed Chip Mounter
• Color：Grey
• Transport Package：Wooden Box
• Specification：CE,UL
• Trademark：ETA
• Origin：Korea
• HS Code：8515190000
• Production Capacity：100 Set,Month

Basic Info.

Model NO. SM471 Type Ultra High-speed Chip Mounter Color Grey Transport Package Wooden Box Specification CE/UL Trademark ETA Origin Korea HS Code 8515190000 Production Capacity 100 Set/Month

Product Description

Sm481, sm481 chip mounter, chip shooter sm481, pick and place machine sm481, SMT machine, SMT mounting, pick and place machine, SMT placement machine, SMT equipment, sm481

Pick & Place Machine - Samsung SM481 Flexible Chipshooter

Highly reliable SM481 is a new generation of chipshooter from Samsung Techwin. Single Gantry with 10 Placement Heads
Cost of ownership is extremely low due to the simple yet reliable X/Y/Z structure.
Easy to use software allows users to quckly learn the machine and get the most from it. Standard component library has more than 1800 shapes and the polygonic algorithm automatically detects component outlines on difficult components.

Features:
Built in vacuum pump making air consumption just 50Nl/min! ! ! !
Easily Identifieable Feeders
Adaptive Pick Up
Front and back operation as standard
Large PCB Size of 460mm X 400mm
01005 component recognition as standard
120 X 8mm Feeder Capacity
High Accuracy ± 50µ @3σ /Chip
Small Footprint of just 1650mm X 1680mm X 1530mm
4.7kVA Max Power

Placement Rate: 39'000cph optimum
Placement Accuracy: ± 50µ @3σ /Chip
± 30µ @3σ /QFP
Component Range: 01005~16mm² By flying vision
Optional Camera available for devices up to 42mm²
Max Height = 10mm, (15mm Optional)
PCB Size: 460mm X 400mm
PCB Thickness: 0.38 ~ 4.2mm
Feeder Capacity: 120 X 8mm

Options:
Fixed Cameras for larger devices
15mm Component height optional (Factory order only)
Board Size 510mm X 460mm
Board Size 610mm X 510mm
Board Size 740mm X 460mm
Intelligent Feeder and Parts system
Feeder Docking Carts
Flux Dipping Feeder


ETA is the leading SMT factory solution provider in China,offering professional SMT factory building
advice and service.We have 20 year experience about SMT factories,offering full solutions for global
clients with our great advantaged sources.Our core technology team members are well experienced in
SMT field, learning experience from top international chip mounters meanwhile increasing independent
research and development. Currently ETA SMT equipment is representative of high quality , has
maintained absolute leading technology in the industry.
Over the years the company has been committed to improving technology, quality and perfect service.
ETA makes a positive contribution to international standard,the annual total capacity of 1200 sets,
passed the ISO9001: 2000, ISO14000, CE, UL, RoHS and other certifications. Full implementation of
the IPD process, reliable design and testing throughout the entire product life cycle.ETA's
continued investment in research and development and great contribution has been unanimously
recognized in the field. By the end of 2012, ETA has declared more than 30 software
copyrights, and actively involved in a number of national and
industry standards. ETA provides more advanced products and fast technical support for global
customers, at home and abroad.


For SMT factory setup,we can do for you:
1. We provide fulL SMT solution for you
2. We provide core technology with our equipments
3. We provide the most professional tech service
4. We have wealthy experience on SMT factory setup
5. We can solve any question about SMT
