• Model NO.：KTU-450
• Product Name：Dual Wave Hot Air PCB Solderin
• Lead Time：20-50days
• Usage：SMT Assembly Line
• Quality：100% Tested
• Weight：1500kg
• Transport Package：Vacuum Packing
• Specification：4500*1600*1730cm
• Trademark：KAIT
• Origin：China
• Production Capacity：50set,Month

Model

KTU-450

Machine parameter

Dimension(L × W × H)

4500*1600*1730

Power supply requiement

3P5W,380V AC 50/60HZ.63A

Total power

25KW

Electric control parameters

Startup power

15KW

Work Power

Approx :3-8KW

Control system

PC+PLC

Preheat system parameter

Preheat model

Hot air

Speed control

Stepless frequency(N/A)

Preheat zone NO.

4

Preheat length

1800mm

Preheat temp

Room Temperature -250ºC

Soldering system

±1.5ºC(by RM board test standard)

Driving type

Mechanical pump ;Over:iron titanium/ball milling cast iron

Heater power

Iron:14.5kw Titannium 15kw

Pot capacity

Lead free:500kg-550kg

Max stove temp

Max 300ºC

Max stove used temp

Max 280ºC

Temp control mode

PID+SSR mode

Wave drive power

1/2HPX2 3P 220V AC

Wave height control

Frequency converter

Warm-up time

About 90min(set:250ºC)

Converying system

PCB conveying speed

0~1800mm/min

Entry height

750±20min(optional:900±20min)

Converyor angle

3º-7º

Converyor motor power

120W 3P 220V AC

PCB width

50-450mm

PCB height

120mm Bottom:25±5mm

Transport accuracy

±2%

N2 system

N2 consumption

15m³/h<1000PPM

Source pressure

0.5-0.8KPa

Other

Flux auto feeding

standard

Flux flow

20-100ml/min

Spray pressure

0.25-0.4MPA

Fan

380V AC 750W

Air tube diameter

Ø200min

Cooling(option)

2HP 2P 220V AC

Center support

Option
